Spring-IoC容器源码导读¶
1.几个重要类/接口¶
阅读前的准备¶
- 源码下载：
- https://github.com/spring-projects/spring-framework
- https://github.com/spring-projects/spring-framework.git
- 源码版本：v5.2.1.RELEASE
1.1 BeanFactory 顶级接口（低配版的IoC容器）¶
BeanFactory接口定义说明¶
- BeanFactory是低配版的IoC容器，定义了Ioc容器基本的功能
完整版源码：¶
Java
/*
* Copyright 2002-2019 the original author or authors.
*
* Licensed under the Apache License, Version 2.0 (the "License");
* you may not use this file except in compliance with the License.
* You may obtain a copy of the License at
*
* https://www.apache.org/licenses/LICENSE-2.0
*
* Unless required by applicable law or agreed to in writing, software
* distributed under the License is distributed on an "AS IS" BASIS,
* WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
* See the License for the specific language governing permissions and
* limitations under the License.
*/
package org.springframework.beans.factory;
import org.springframework.beans.BeansException;
import org.springframework.core.ResolvableType;
import org.springframework.lang.Nullable;
/**
* The root interface for accessing a Spring bean container.
* This is the basic client view of a bean container;
* further interfaces such as {@link ListableBeanFactory} and
* {@link org.springframework.beans.factory.config.ConfigurableBeanFactory}
* are available for specific purposes.
*
* <p>This interface is implemented by objects that hold a number of bean definitions,
* each uniquely identified by a String name. Depending on the bean definition,
* the factory will return either an independent instance of a contained object
* (the Prototype design pattern), or a single shared instance (a superior
* alternative to the Singleton design pattern, in which the instance is a
* singleton in the scope of the factory). Which type of instance will be returned
* depends on the bean factory configuration: the API is the same. Since Spring
* 2.0, further scopes are available depending on the concrete application
* context (e.g. "request" and "session" scopes in a web environment).
*
* <p>The point of this approach is that the BeanFactory is a central registry
* of application components, and centralizes configuration of application
* components (no more do individual objects need to read properties files,
* for example). See chapters 4 and 11 of "Expert One-on-One J2EE Design and
* Development" for a discussion of the benefits of this approach.
*
* <p>Note that it is generally better to rely on Dependency Injection
* ("push" configuration) to configure application objects through setters
* or constructors, rather than use any form of "pull" configuration like a
* BeanFactory lookup. Spring's Dependency Injection functionality is
* implemented using this BeanFactory interface and its subinterfaces.
*
* <p>Normally a BeanFactory will load bean definitions stored in a configuration
* source (such as an XML document), and use the {@code org.springframework.beans}
* package to configure the beans. However, an implementation could simply return
* Java objects it creates as necessary directly in Java code. There are no
* constraints on how the definitions could be stored: LDAP, RDBMS, XML,
* properties file, etc. Implementations are encouraged to support references
* amongst beans (Dependency Injection).
*
* <p>In contrast to the methods in {@link ListableBeanFactory}, all of the
* operations in this interface will also check parent factories if this is a
* {@link HierarchicalBeanFactory}. If a bean is not found in this factory instance,
* the immediate parent factory will be asked. Beans in this factory instance
* are supposed to override beans of the same name in any parent factory.
*
* <p>Bean factory implementations should support the standard bean lifecycle interfaces
* as far as possible. The full set of initialization methods and their standard order is:
* <ol>
* <li>BeanNameAware's {@code setBeanName}
* <li>BeanClassLoaderAware's {@code setBeanClassLoader}
* <li>BeanFactoryAware's {@code setBeanFactory}
* <li>EnvironmentAware's {@code setEnvironment}
* <li>EmbeddedValueResolverAware's {@code setEmbeddedValueResolver}
* <li>ResourceLoaderAware's {@code setResourceLoader}
* (only applicable when running in an application context)
* <li>ApplicationEventPublisherAware's {@code setApplicationEventPublisher}
* (only applicable when running in an application context)
* <li>MessageSourceAware's {@code setMessageSource}
* (only applicable when running in an application context)
* <li>ApplicationContextAware's {@code setApplicationContext}
* (only applicable when running in an application context)
* <li>ServletContextAware's {@code setServletContext}
* (only applicable when running in a web application context)
* <li>{@code postProcessBeforeInitialization} methods of BeanPostProcessors
* <li>InitializingBean's {@code afterPropertiesSet}
* <li>a custom init-method definition
* <li>{@code postProcessAfterInitialization} methods of BeanPostProcessors
* </ol>
*
* <p>On shutdown of a bean factory, the following lifecycle methods apply:
* <ol>
* <li>{@code postProcessBeforeDestruction} methods of DestructionAwareBeanPostProcessors
* <li>DisposableBean's {@code destroy}
* <li>a custom destroy-method definition
* </ol>
*
* @author Rod Johnson
* @author Juergen Hoeller
* @author Chris Beams
* @since 13 April 2001
* @see BeanNameAware#setBeanName
* @see BeanClassLoaderAware#setBeanClassLoader
* @see BeanFactoryAware#setBeanFactory
* @see org.springframework.context.ResourceLoaderAware#setResourceLoader
* @see org.springframework.context.ApplicationEventPublisherAware#setApplicationEventPublisher
* @see org.springframework.context.MessageSourceAware#setMessageSource
* @see org.springframework.context.ApplicationContextAware#setApplicationContext
* @see org.springframework.web.context.ServletContextAware#setServletContext
* @see org.springframework.beans.factory.config.BeanPostProcessor#postProcessBeforeInitialization
* @see InitializingBean#afterPropertiesSet
* @see org.springframework.beans.factory.support.RootBeanDefinition#getInitMethodName
* @see org.springframework.beans.factory.config.BeanPostProcessor#postProcessAfterInitialization
* @see DisposableBean#destroy
* @see org.springframework.beans.factory.support.RootBeanDefinition#getDestroyMethodName
*/
public interface BeanFactory {
/**
* Used to dereference a {@link FactoryBean} instance and distinguish it from
* beans <i>created</i> by the FactoryBean. For example, if the bean named
* {@code myJndiObject} is a FactoryBean, getting {@code &myJndiObject}
* will return the factory, not the instance returned by the factory.
*/
String FACTORY_BEAN_PREFIX = "&";
/**
* Return an instance, which may be shared or independent, of the specified bean.
* <p>This method allows a Spring BeanFactory to be used as a replacement for the
* Singleton or Prototype design pattern. Callers may retain references to
* returned objects in the case of Singleton beans.
* <p>Translates aliases back to the corresponding canonical bean name.
* Will ask the parent factory if the bean cannot be found in this factory instance.
* @param name the name of the bean to retrieve
* @return an instance of the bean
* @throws NoSuchBeanDefinitionException if there is no bean with the specified name
* @throws BeansException if the bean could not be obtained
*/
Object getBean(String name) throws BeansException;
/**
* Return an instance, which may be shared or independent, of the specified bean.
* <p>Behaves the same as {@link #getBean(String)}, but provides a measure of type
* safety by throwing a BeanNotOfRequiredTypeException if the bean is not of the
* required type. This means that ClassCastException can't be thrown on casting
* the result correctly, as can happen with {@link #getBean(String)}.
* <p>Translates aliases back to the corresponding canonical bean name.
* Will ask the parent factory if the bean cannot be found in this factory instance.
* @param name the name of the bean to retrieve
* @param requiredType type the bean must match; can be an interface or superclass
* @return an instance of the bean
* @throws NoSuchBeanDefinitionException if there is no such bean definition
* @throws BeanNotOfRequiredTypeException if the bean is not of the required type
* @throws BeansException if the bean could not be created
*/
<T> T getBean(String name, Class<T> requiredType) throws BeansException;
/**
* Return an instance, which may be shared or independent, of the specified bean.
* <p>Allows for specifying explicit constructor arguments / factory method arguments,
* overriding the specified default arguments (if any) in the bean definition.
* @param name the name of the bean to retrieve
* @param args arguments to use when creating a bean instance using explicit arguments
* (only applied when creating a new instance as opposed to retrieving an existing one)
* @return an instance of the bean
* @throws NoSuchBeanDefinitionException if there is no such bean definition
* @throws BeanDefinitionStoreException if arguments have been given but
* the affected bean isn't a prototype
* @throws BeansException if the bean could not be created
* @since 2.5
*/
Object getBean(String name, Object... args) throws BeansException;
/**
* Return the bean instance that uniquely matches the given object type, if any.
* <p>This method goes into {@link ListableBeanFactory} by-type lookup territory
* but may also be translated into a conventional by-name lookup based on the name
* of the given type. For more extensive retrieval operations across sets of beans,
* use {@link ListableBeanFactory} and/or {@link BeanFactoryUtils}.
* @param requiredType type the bean must match; can be an interface or superclass
* @return an instance of the single bean matching the required type
* @throws NoSuchBeanDefinitionException if no bean of the given type was found
* @throws NoUniqueBeanDefinitionException if more than one bean of the given type was found
* @throws BeansException if the bean could not be created
* @since 3.0
* @see ListableBeanFactory
*/
<T> T getBean(Class<T> requiredType) throws BeansException;
/**
* Return an instance, which may be shared or independent, of the specified bean.
* <p>Allows for specifying explicit constructor arguments / factory method arguments,
* overriding the specified default arguments (if any) in the bean definition.
* <p>This method goes into {@link ListableBeanFactory} by-type lookup territory
* but may also be translated into a conventional by-name lookup based on the name
* of the given type. For more extensive retrieval operations across sets of beans,
* use {@link ListableBeanFactory} and/or {@link BeanFactoryUtils}.
* @param requiredType type the bean must match; can be an interface or superclass
* @param args arguments to use when creating a bean instance using explicit arguments
* (only applied when creating a new instance as opposed to retrieving an existing one)
* @return an instance of the bean
* @throws NoSuchBeanDefinitionException if there is no such bean definition
* @throws BeanDefinitionStoreException if arguments have been given but
* the affected bean isn't a prototype
* @throws BeansException if the bean could not be created
* @since 4.1
*/
<T> T getBean(Class<T> requiredType, Object... args) throws BeansException;
/**
* Return a provider for the specified bean, allowing for lazy on-demand retrieval
* of instances, including availability and uniqueness options.
* @param requiredType type the bean must match; can be an interface or superclass
* @return a corresponding provider handle
* @since 5.1
* @see #getBeanProvider(ResolvableType)
*/
<T> ObjectProvider<T> getBeanProvider(Class<T> requiredType);
/**
* Return a provider for the specified bean, allowing for lazy on-demand retrieval
* of instances, including availability and uniqueness options.
* @param requiredType type the bean must match; can be a generic type declaration.
* Note that collection types are not supported here, in contrast to reflective
* injection points. For programmatically retrieving a list of beans matching a
* specific type, specify the actual bean type as an argument here and subsequently
* use {@link ObjectProvider#orderedStream()} or its lazy streaming/iteration options.
* @return a corresponding provider handle
* @since 5.1
* @see ObjectProvider#iterator()
* @see ObjectProvider#stream()
* @see ObjectProvider#orderedStream()
*/
<T> ObjectProvider<T> getBeanProvider(ResolvableType requiredType);
/**
* Does this bean factory contain a bean definition or externally registered singleton
* instance with the given name?
* <p>If the given name is an alias, it will be translated back to the corresponding
* canonical bean name.
* <p>If this factory is hierarchical, will ask any parent factory if the bean cannot
* be found in this factory instance.
* <p>If a bean definition or singleton instance matching the given name is found,
* this method will return {@code true} whether the named bean definition is concrete
* or abstract, lazy or eager, in scope or not. Therefore, note that a {@code true}
* return value from this method does not necessarily indicate that {@link #getBean}
* will be able to obtain an instance for the same name.
* @param name the name of the bean to query
* @return whether a bean with the given name is present
*/
boolean containsBean(String name);
/**
* Is this bean a shared singleton? That is, will {@link #getBean} always
* return the same instance?
* <p>Note: This method returning {@code false} does not clearly indicate
* independent instances. It indicates non-singleton instances, which may correspond
* to a scoped bean as well. Use the {@link #isPrototype} operation to explicitly
* check for independent instances.
* <p>Translates aliases back to the corresponding canonical bean name.
* Will ask the parent factory if the bean cannot be found in this factory instance.
* @param name the name of the bean to query
* @return whether this bean corresponds to a singleton instance
* @throws NoSuchBeanDefinitionException if there is no bean with the given name
* @see #getBean
* @see #isPrototype
*/
boolean isSingleton(String name) throws NoSuchBeanDefinitionException;
/**
* Is this bean a prototype? That is, will {@link #getBean} always return
* independent instances?
* <p>Note: This method returning {@code false} does not clearly indicate
* a singleton object. It indicates non-independent instances, which may correspond
* to a scoped bean as well. Use the {@link #isSingleton} operation to explicitly
* check for a shared singleton instance.
* <p>Translates aliases back to the corresponding canonical bean name.
* Will ask the parent factory if the bean cannot be found in this factory instance.
* @param name the name of the bean to query
* @return whether this bean will always deliver independent instances
* @throws NoSuchBeanDefinitionException if there is no bean with the given name
* @since 2.0.3
* @see #getBean
* @see #isSingleton
*/
boolean isPrototype(String name) throws NoSuchBeanDefinitionException;
/**
* Check whether the bean with the given name matches the specified type.
* More specifically, check whether a {@link #getBean} call for the given name
* would return an object that is assignable to the specified target type.
* <p>Translates aliases back to the corresponding canonical bean name.
* Will ask the parent factory if the bean cannot be found in this factory instance.
* @param name the name of the bean to query
* @param typeToMatch the type to match against (as a {@code ResolvableType})
* @return {@code true} if the bean type matches,
* {@code false} if it doesn't match or cannot be determined yet
* @throws NoSuchBeanDefinitionException if there is no bean with the given name
* @since 4.2
* @see #getBean
* @see #getType
*/
boolean isTypeMatch(String name, ResolvableType typeToMatch) throws NoSuchBeanDefinitionException;
/**
* Check whether the bean with the given name matches the specified type.
* More specifically, check whether a {@link #getBean} call for the given name
* would return an object that is assignable to the specified target type.
* <p>Translates aliases back to the corresponding canonical bean name.
* Will ask the parent factory if the bean cannot be found in this factory instance.
* @param name the name of the bean to query
* @param typeToMatch the type to match against (as a {@code Class})
* @return {@code true} if the bean type matches,
* {@code false} if it doesn't match or cannot be determined yet
* @throws NoSuchBeanDefinitionException if there is no bean with the given name
* @since 2.0.1
* @see #getBean
* @see #getType
*/
boolean isTypeMatch(String name, Class<?> typeToMatch) throws NoSuchBeanDefinitionException;
/**
* Determine the type of the bean with the given name. More specifically,
* determine the type of object that {@link #getBean} would return for the given name.
* <p>For a {@link FactoryBean}, return the type of object that the FactoryBean creates,
* as exposed by {@link FactoryBean#getObjectType()}. This may lead to the initialization
* of a previously uninitialized {@code FactoryBean} (see {@link #getType(String, boolean)}).
* <p>Translates aliases back to the corresponding canonical bean name.
* Will ask the parent factory if the bean cannot be found in this factory instance.
* @param name the name of the bean to query
* @return the type of the bean, or {@code null} if not determinable
* @throws NoSuchBeanDefinitionException if there is no bean with the given name
* @since 1.1.2
* @see #getBean
* @see #isTypeMatch
*/
@Nullable
Class<?> getType(String name) throws NoSuchBeanDefinitionException;
/**
* Determine the type of the bean with the given name. More specifically,
* determine the type of object that {@link #getBean} would return for the given name.
* <p>For a {@link FactoryBean}, return the type of object that the FactoryBean creates,
* as exposed by {@link FactoryBean#getObjectType()}. Depending on the
* {@code allowFactoryBeanInit} flag, this may lead to the initialization of a previously
* uninitialized {@code FactoryBean} if no early type information is available.
* <p>Translates aliases back to the corresponding canonical bean name.
* Will ask the parent factory if the bean cannot be found in this factory instance.
* @param name the name of the bean to query
* @param allowFactoryBeanInit whether a {@code FactoryBean} may get initialized
* just for the purpose of determining its object type
* @return the type of the bean, or {@code null} if not determinable
* @throws NoSuchBeanDefinitionException if there is no bean with the given name
* @since 5.2
* @see #getBean
* @see #isTypeMatch
*/
@Nullable
Class<?> getType(String name, boolean allowFactoryBeanInit) throws NoSuchBeanDefinitionException;
/**
* Return the aliases for the given bean name, if any.
* All of those aliases point to the same bean when used in a {@link #getBean} call.
* <p>If the given name is an alias, the corresponding original bean name
* and other aliases (if any) will be returned, with the original bean name
* being the first element in the array.
* <p>Will ask the parent factory if the bean cannot be found in this factory instance.
* @param name the bean name to check for aliases
* @return the aliases, or an empty array if none
* @see #getBean
*/
String[] getAliases(String name);
}
BeanFactory方法属性摘要¶
Java
public interface BeanFactory {
/**
*/
String FACTORY_BEAN_PREFIX = "&";
/**
*/
Object getBean(String name) throws BeansException;
/**
*/
<T> T getBean(String name, Class<T> requiredType) throws BeansException;
/**
*/
Object getBean(String name, Object... args) throws BeansException;
/**
*/
<T> T getBean(Class<T> requiredType) throws BeansException;
/**
*/
<T> T getBean(Class<T> requiredType, Object... args) throws BeansException;
/**
*/
<T> ObjectProvider<T> getBeanProvider(Class<T> requiredType);
/**
*/
<T> ObjectProvider<T> getBeanProvider(ResolvableType requiredType);
/**
*/
boolean containsBean(String name);
/**
*/
boolean isSingleton(String name) throws NoSuchBeanDefinitionException;
/**
*/
boolean isPrototype(String name) throws NoSuchBeanDefinitionException;
/**
*/
boolean isTypeMatch(String name, ResolvableType typeToMatch) throws NoSuchBeanDefinitionException;
/**
*/
boolean isTypeMatch(String name, Class<?> typeToMatch) throws NoSuchBeanDefinitionException;
/**
*/
@Nullable
Class<?> getType(String name) throws NoSuchBeanDefinitionException;
/**
*/
@Nullable
Class<?> getType(String name, boolean allowFactoryBeanInit) throws NoSuchBeanDefinitionException;
/**
*/
String[] getAliases(String name);
}
1.2 HierarchicalBeanFactory接口¶
完整版源码：¶
Java
/*
* Copyright 2002-2012 the original author or authors.
*
* Licensed under the Apache License, Version 2.0 (the "License");
* you may not use this file except in compliance with the License.
* You may obtain a copy of the License at
*
* https://www.apache.org/licenses/LICENSE-2.0
*
* Unless required by applicable law or agreed to in writing, software
* distributed under the License is distributed on an "AS IS" BASIS,
* WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
* See the License for the specific language governing permissions and
* limitations under the License.
*/
package org.springframework.beans.factory;
import org.springframework.lang.Nullable;
/**
* Sub-interface implemented by bean factories that can be part
* of a hierarchy.
*
* <p>The corresponding {@code setParentBeanFactory} method for bean
* factories that allow setting the parent in a configurable
* fashion can be found in the ConfigurableBeanFactory interface.
*
* @author Rod Johnson
* @author Juergen Hoeller
* @since 07.07.2003
* @see org.springframework.beans.factory.config.ConfigurableBeanFactory#setParentBeanFactory
*/
public interface HierarchicalBeanFactory extends BeanFactory {
/**
* Return the parent bean factory, or {@code null} if there is none.
*/
@Nullable
BeanFactory getParentBeanFactory();
/**
* Return whether the local bean factory contains a bean of the given name,
* ignoring beans defined in ancestor contexts.
* <p>This is an alternative to {@code containsBean}, ignoring a bean
* of the given name from an ancestor bean factory.
* @param name the name of the bean to query
* @return whether a bean with the given name is defined in the local factory
* @see BeanFactory#containsBean
*/
boolean containsLocalBean(String name);
}
HierarchicalBeanFactory方法属性摘要¶
Java
public interface HierarchicalBeanFactory extends BeanFactory {
/**
*/
@Nullable
BeanFactory getParentBeanFactory();
/**
*/
boolean containsLocalBean(String name);
}
1.3 ListableBeanFactory接口¶
完整版源码：¶
Java
/*
* Copyright 2002-2019 the original author or authors.
*
* Licensed under the Apache License, Version 2.0 (the "License");
* you may not use this file except in compliance with the License.
* You may obtain a copy of the License at
*
* https://www.apache.org/licenses/LICENSE-2.0
*
* Unless required by applicable law or agreed to in writing, software
* distributed under the License is distributed on an "AS IS" BASIS,
* WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
* See the License for the specific language governing permissions and
* limitations under the License.
*/
package org.springframework.beans.factory;
import java.lang.annotation.Annotation;
import java.util.Map;
import org.springframework.beans.BeansException;
import org.springframework.core.ResolvableType;
import org.springframework.lang.Nullable;
/**
* Extension of the {@link BeanFactory} interface to be implemented by bean factories
* that can enumerate all their bean instances, rather than attempting bean lookup
* by name one by one as requested by clients. BeanFactory implementations that
* preload all their bean definitions (such as XML-based factories) may implement
* this interface.
*
* <p>If this is a {@link HierarchicalBeanFactory}, the return values will <i>not</i>
* take any BeanFactory hierarchy into account, but will relate only to the beans
* defined in the current factory. Use the {@link BeanFactoryUtils} helper class
* to consider beans in ancestor factories too.
*
* <p>The methods in this interface will just respect bean definitions of this factory.
* They will ignore any singleton beans that have been registered by other means like
* {@link org.springframework.beans.factory.config.ConfigurableBeanFactory}'s
* {@code registerSingleton} method, with the exception of
* {@code getBeanNamesOfType} and {@code getBeansOfType} which will check
* such manually registered singletons too. Of course, BeanFactory's {@code getBean}
* does allow transparent access to such special beans as well. However, in typical
* scenarios, all beans will be defined by external bean definitions anyway, so most
* applications don't need to worry about this differentiation.
*
* <p><b>NOTE:</b> With the exception of {@code getBeanDefinitionCount}
* and {@code containsBeanDefinition}, the methods in this interface
* are not designed for frequent invocation. Implementations may be slow.
*
* @author Rod Johnson
* @author Juergen Hoeller
* @since 16 April 2001
* @see HierarchicalBeanFactory
* @see BeanFactoryUtils
*/
public interface ListableBeanFactory extends BeanFactory {
/**
* Check if this bean factory contains a bean definition with the given name.
* <p>Does not consider any hierarchy this factory may participate in,
* and ignores any singleton beans that have been registered by
* other means than bean definitions.
* @param beanName the name of the bean to look for
* @return if this bean factory contains a bean definition with the given name
* @see #containsBean
*/
boolean containsBeanDefinition(String beanName);
/**
* Return the number of beans defined in the factory.
* <p>Does not consider any hierarchy this factory may participate in,
* and ignores any singleton beans that have been registered by
* other means than bean definitions.
* @return the number of beans defined in the factory
*/
int getBeanDefinitionCount();
/**
* Return the names of all beans defined in this factory.
* <p>Does not consider any hierarchy this factory may participate in,
* and ignores any singleton beans that have been registered by
* other means than bean definitions.
* @return the names of all beans defined in this factory,
* or an empty array if none defined
*/
String[] getBeanDefinitionNames();
/**
* Return the names of beans matching the given type (including subclasses),
* judging from either bean definitions or the value of {@code getObjectType}
* in the case of FactoryBeans.
* <p><b>NOTE: This method introspects top-level beans only.</b> It does <i>not</i>
* check nested beans which might match the specified type as well.
* <p>Does consider objects created by FactoryBeans, which means that FactoryBeans
* will get initialized. If the object created by the FactoryBean doesn't match,
* the raw FactoryBean itself will be matched against the type.
* <p>Does not consider any hierarchy this factory may participate in.
* Use BeanFactoryUtils' {@code beanNamesForTypeIncludingAncestors}
* to include beans in ancestor factories too.
* <p>Note: Does <i>not</i> ignore singleton beans that have been registered
* by other means than bean definitions.
* <p>This version of {@code getBeanNamesForType} matches all kinds of beans,
* be it singletons, prototypes, or FactoryBeans. In most implementations, the
* result will be the same as for {@code getBeanNamesForType(type, true, true)}.
* <p>Bean names returned by this method should always return bean names <i>in the
* order of definition</i> in the backend configuration, as far as possible.
* @param type the generically typed class or interface to match
* @return the names of beans (or objects created by FactoryBeans) matching
* the given object type (including subclasses), or an empty array if none
* @since 4.2
* @see #isTypeMatch(String, ResolvableType)
* @see FactoryBean#getObjectType
* @see BeanFactoryUtils#beanNamesForTypeIncludingAncestors(ListableBeanFactory, ResolvableType)
*/
String[] getBeanNamesForType(ResolvableType type);
/**
* Return the names of beans matching the given type (including subclasses),
* judging from either bean definitions or the value of {@code getObjectType}
* in the case of FactoryBeans.
* <p><b>NOTE: This method introspects top-level beans only.</b> It does <i>not</i>
* check nested beans which might match the specified type as well.
* <p>Does consider objects created by FactoryBeans if the "allowEagerInit" flag is set,
* which means that FactoryBeans will get initialized. If the object created by the
* FactoryBean doesn't match, the raw FactoryBean itself will be matched against the
* type. If "allowEagerInit" is not set, only raw FactoryBeans will be checked
* (which doesn't require initialization of each FactoryBean).
* <p>Does not consider any hierarchy this factory may participate in.
* Use BeanFactoryUtils' {@code beanNamesForTypeIncludingAncestors}
* to include beans in ancestor factories too.
* <p>Note: Does <i>not</i> ignore singleton beans that have been registered
* by other means than bean definitions.
* <p>Bean names returned by this method should always return bean names <i>in the
* order of definition</i> in the backend configuration, as far as possible.
* @param type the generically typed class or interface to match
* @param includeNonSingletons whether to include prototype or scoped beans too
* or just singletons (also applies to FactoryBeans)
* @param allowEagerInit whether to initialize <i>lazy-init singletons</i> and
* <i>objects created by FactoryBeans</i> (or by factory methods with a
* "factory-bean" reference) for the type check. Note that FactoryBeans need to be
* eagerly initialized to determine their type: So be aware that passing in "true"
* for this flag will initialize FactoryBeans and "factory-bean" references.
* @return the names of beans (or objects created by FactoryBeans) matching
* the given object type (including subclasses), or an empty array if none
* @since 5.2
* @see FactoryBean#getObjectType
* @see BeanFactoryUtils#beanNamesForTypeIncludingAncestors(ListableBeanFactory, ResolvableType, boolean, boolean)
*/
String[] getBeanNamesForType(ResolvableType type, boolean includeNonSingletons, boolean allowEagerInit);
/**
* Return the names of beans matching the given type (including subclasses),
* judging from either bean definitions or the value of {@code getObjectType}
* in the case of FactoryBeans.
* <p><b>NOTE: This method introspects top-level beans only.</b> It does <i>not</i>
* check nested beans which might match the specified type as well.
* <p>Does consider objects created by FactoryBeans, which means that FactoryBeans
* will get initialized. If the object created by the FactoryBean doesn't match,
* the raw FactoryBean itself will be matched against the type.
* <p>Does not consider any hierarchy this factory may participate in.
* Use BeanFactoryUtils' {@code beanNamesForTypeIncludingAncestors}
* to include beans in ancestor factories too.
* <p>Note: Does <i>not</i> ignore singleton beans that have been registered
* by other means than bean definitions.
* <p>This version of {@code getBeanNamesForType} matches all kinds of beans,
* be it singletons, prototypes, or FactoryBeans. In most implementations, the
* result will be the same as for {@code getBeanNamesForType(type, true, true)}.
* <p>Bean names returned by this method should always return bean names <i>in the
* order of definition</i> in the backend configuration, as far as possible.
* @param type the class or interface to match, or {@code null} for all bean names
* @return the names of beans (or objects created by FactoryBeans) matching
* the given object type (including subclasses), or an empty array if none
* @see FactoryBean#getObjectType
* @see BeanFactoryUtils#beanNamesForTypeIncludingAncestors(ListableBeanFactory, Class)
*/
String[] getBeanNamesForType(@Nullable Class<?> type);
/**
* Return the names of beans matching the given type (including subclasses),
* judging from either bean definitions or the value of {@code getObjectType}
* in the case of FactoryBeans.
* <p><b>NOTE: This method introspects top-level beans only.</b> It does <i>not</i>
* check nested beans which might match the specified type as well.
* <p>Does consider objects created by FactoryBeans if the "allowEagerInit" flag is set,
* which means that FactoryBeans will get initialized. If the object created by the
* FactoryBean doesn't match, the raw FactoryBean itself will be matched against the
* type. If "allowEagerInit" is not set, only raw FactoryBeans will be checked
* (which doesn't require initialization of each FactoryBean).
* <p>Does not consider any hierarchy this factory may participate in.
* Use BeanFactoryUtils' {@code beanNamesForTypeIncludingAncestors}
* to include beans in ancestor factories too.
* <p>Note: Does <i>not</i> ignore singleton beans that have been registered
* by other means than bean definitions.
* <p>Bean names returned by this method should always return bean names <i>in the
* order of definition</i> in the backend configuration, as far as possible.
* @param type the class or interface to match, or {@code null} for all bean names
* @param includeNonSingletons whether to include prototype or scoped beans too
* or just singletons (also applies to FactoryBeans)
* @param allowEagerInit whether to initialize <i>lazy-init singletons</i> and
* <i>objects created by FactoryBeans</i> (or by factory methods with a
* "factory-bean" reference) for the type check. Note that FactoryBeans need to be
* eagerly initialized to determine their type: So be aware that passing in "true"
* for this flag will initialize FactoryBeans and "factory-bean" references.
* @return the names of beans (or objects created by FactoryBeans) matching
* the given object type (including subclasses), or an empty array if none
* @see FactoryBean#getObjectType
* @see BeanFactoryUtils#beanNamesForTypeIncludingAncestors(ListableBeanFactory, Class, boolean, boolean)
*/
String[] getBeanNamesForType(@Nullable Class<?> type, boolean includeNonSingletons, boolean allowEagerInit);
/**
* Return the bean instances that match the given object type (including
* subclasses), judging from either bean definitions or the value of
* {@code getObjectType} in the case of FactoryBeans.
* <p><b>NOTE: This method introspects top-level beans only.</b> It does <i>not</i>
* check nested beans which might match the specified type as well.
* <p>Does consider objects created by FactoryBeans, which means that FactoryBeans
* will get initialized. If the object created by the FactoryBean doesn't match,
* the raw FactoryBean itself will be matched against the type.
* <p>Does not consider any hierarchy this factory may participate in.
* Use BeanFactoryUtils' {@code beansOfTypeIncludingAncestors}
* to include beans in ancestor factories too.
* <p>Note: Does <i>not</i> ignore singleton beans that have been registered
* by other means than bean definitions.
* <p>This version of getBeansOfType matches all kinds of beans, be it
* singletons, prototypes, or FactoryBeans. In most implementations, the
* result will be the same as for {@code getBeansOfType(type, true, true)}.
* <p>The Map returned by this method should always return bean names and
* corresponding bean instances <i>in the order of definition</i> in the
* backend configuration, as far as possible.
* @param type the class or interface to match, or {@code null} for all concrete beans
* @return a Map with the matching beans, containing the bean names as
* keys and the corresponding bean instances as values
* @throws BeansException if a bean could not be created
* @since 1.1.2
* @see FactoryBean#getObjectType
* @see BeanFactoryUtils#beansOfTypeIncludingAncestors(ListableBeanFactory, Class)
*/
<T> Map<String, T> getBeansOfType(@Nullable Class<T> type) throws BeansException;
/**
* Return the bean instances that match the given object type (including
* subclasses), judging from either bean definitions or the value of
* {@code getObjectType} in the case of FactoryBeans.
* <p><b>NOTE: This method introspects top-level beans only.</b> It does <i>not</i>
* check nested beans which might match the specified type as well.
* <p>Does consider objects created by FactoryBeans if the "allowEagerInit" flag is set,
* which means that FactoryBeans will get initialized. If the object created by the
* FactoryBean doesn't match, the raw FactoryBean itself will be matched against the
* type. If "allowEagerInit" is not set, only raw FactoryBeans will be checked
* (which doesn't require initialization of each FactoryBean).
* <p>Does not consider any hierarchy this factory may participate in.
* Use BeanFactoryUtils' {@code beansOfTypeIncludingAncestors}
* to include beans in ancestor factories too.
* <p>Note: Does <i>not</i> ignore singleton beans that have been registered
* by other means than bean definitions.
* <p>The Map returned by this method should always return bean names and
* corresponding bean instances <i>in the order of definition</i> in the
* backend configuration, as far as possible.
* @param type the class or interface to match, or {@code null} for all concrete beans
* @param includeNonSingletons whether to include prototype or scoped beans too
* or just singletons (also applies to FactoryBeans)
* @param allowEagerInit whether to initialize <i>lazy-init singletons</i> and
* <i>objects created by FactoryBeans</i> (or by factory methods with a
* "factory-bean" reference) for the type check. Note that FactoryBeans need to be
* eagerly initialized to determine their type: So be aware that passing in "true"
* for this flag will initialize FactoryBeans and "factory-bean" references.
* @return a Map with the matching beans, containing the bean names as
* keys and the corresponding bean instances as values
* @throws BeansException if a bean could not be created
* @see FactoryBean#getObjectType
* @see BeanFactoryUtils#beansOfTypeIncludingAncestors(ListableBeanFactory, Class, boolean, boolean)
*/
<T> Map<String, T> getBeansOfType(@Nullable Class<T> type, boolean includeNonSingletons, boolean allowEagerInit)
throws BeansException;
/**
* Find all names of beans which are annotated with the supplied {@link Annotation}
* type, without creating corresponding bean instances yet.
* <p>Note that this method considers objects created by FactoryBeans, which means
* that FactoryBeans will get initialized in order to determine their object type.
* @param annotationType the type of annotation to look for
* (at class, interface or factory method level of the specified bean)
* @return the names of all matching beans
* @since 4.0
* @see #findAnnotationOnBean
*/
String[] getBeanNamesForAnnotation(Class<? extends Annotation> annotationType);
/**
* Find all beans which are annotated with the supplied {@link Annotation} type,
* returning a Map of bean names with corresponding bean instances.
* <p>Note that this method considers objects created by FactoryBeans, which means
* that FactoryBeans will get initialized in order to determine their object type.
* @param annotationType the type of annotation to look for
* (at class, interface or factory method level of the specified bean)
* @return a Map with the matching beans, containing the bean names as
* keys and the corresponding bean instances as values
* @throws BeansException if a bean could not be created
* @since 3.0
* @see #findAnnotationOnBean
*/
Map<String, Object> getBeansWithAnnotation(Class<? extends Annotation> annotationType) throws BeansException;
/**
* Find an {@link Annotation} of {@code annotationType} on the specified bean,
* traversing its interfaces and super classes if no annotation can be found on
* the given class itself, as well as checking the bean's factory method (if any).
* @param beanName the name of the bean to look for annotations on
* @param annotationType the type of annotation to look for
* (at class, interface or factory method level of the specified bean)
* @return the annotation of the given type if found, or {@code null} otherwise
* @throws NoSuchBeanDefinitionException if there is no bean with the given name
* @since 3.0
* @see #getBeanNamesForAnnotation
* @see #getBeansWithAnnotation
*/
@Nullable
<A extends Annotation> A findAnnotationOnBean(String beanName, Class<A> annotationType)
throws NoSuchBeanDefinitionException;
}
ListableBeanFactory方法属性摘要¶
Java
public interface ListableBeanFactory extends BeanFactory {
/**
*/
boolean containsBeanDefinition(String beanName);
/**
*/
int getBeanDefinitionCount();
/**
*/
String[] getBeanDefinitionNames();
/**
*/
String[] getBeanNamesForType(ResolvableType type);
/**
*/
String[] getBeanNamesForType(ResolvableType type, boolean includeNonSingletons, boolean allowEagerInit);
/**
*/
String[] getBeanNamesForType(@Nullable Class<?> type);
/**
*/
String[] getBeanNamesForType(@Nullable Class<?> type, boolean includeNonSingletons, boolean allowEagerInit);
<T> Map<String, T> getBeansOfType(@Nullable Class<T> type) throws BeansException;
<T> Map<String, T> getBeansOfType(@Nullable Class<T> type, boolean includeNonSingletons, boolean allowEagerInit)
throws BeansException;
String[] getBeanNamesForAnnotation(Class<? extends Annotation> annotationType);
Map<String, Object> getBeansWithAnnotation(Class<? extends Annotation> annotationType) throws BeansException;
@Nullable
<A extends Annotation> A findAnnotationOnBean(String beanName, Class<A> annotationType)
throws NoSuchBeanDefinitionException;
}
1.4 ApplicationContext接口¶
ApplicationContext接口解析¶
- 相比于BeanFactory,ApplicationContext是高配版的Ioc容器，其在BeanFactory的基础上实现了更加复杂的扩展功能
- ListableBeanFactory, HierarchicalBeanFactory都是BeanFactory的子接口，ApplicationContext继承了这两个接口，ApplicationContext进一步扩展了BeanFactory接口的功能
- . . .
完整版源码：¶
Java
/*
* Copyright 2002-2014 the original author or authors.
*
* Licensed under the Apache License, Version 2.0 (the "License");
* you may not use this file except in compliance with the License.
* You may obtain a copy of the License at
*
* https://www.apache.org/licenses/LICENSE-2.0
*
* Unless required by applicable law or agreed to in writing, software
* distributed under the License is distributed on an "AS IS" BASIS,
* WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
* See the License for the specific language governing permissions and
* limitations under the License.
*/
package org.springframework.context;
import org.springframework.beans.factory.HierarchicalBeanFactory;
import org.springframework.beans.factory.ListableBeanFactory;
import org.springframework.beans.factory.config.AutowireCapableBeanFactory;
import org.springframework.core.env.EnvironmentCapable;
import org.springframework.core.io.support.ResourcePatternResolver;
import org.springframework.lang.Nullable;
/**
* Central interface to provide configuration for an application.
* This is read-only while the application is running, but may be
* reloaded if the implementation supports this.
*
* <p>An ApplicationContext provides:
* <ul>
* <li>Bean factory methods for accessing application components.
* Inherited from {@link org.springframework.beans.factory.ListableBeanFactory}.
* <li>The ability to load file resources in a generic fashion.
* Inherited from the {@link org.springframework.core.io.ResourceLoader} interface.
* <li>The ability to publish events to registered listeners.
* Inherited from the {@link ApplicationEventPublisher} interface.
* <li>The ability to resolve messages, supporting internationalization.
* Inherited from the {@link MessageSource} interface.
* <li>Inheritance from a parent context. Definitions in a descendant context
* will always take priority. This means, for example, that a single parent
* context can be used by an entire web application, while each servlet has
* its own child context that is independent of that of any other servlet.
* </ul>
*
* <p>In addition to standard {@link org.springframework.beans.factory.BeanFactory}
* lifecycle capabilities, ApplicationContext implementations detect and invoke
* {@link ApplicationContextAware} beans as well as {@link ResourceLoaderAware},
* {@link ApplicationEventPublisherAware} and {@link MessageSourceAware} beans.
*
* @author Rod Johnson
* @author Juergen Hoeller
* @see ConfigurableApplicationContext
* @see org.springframework.beans.factory.BeanFactory
* @see org.springframework.core.io.ResourceLoader
*/
public interface ApplicationContext extends EnvironmentCapable, ListableBeanFactory, HierarchicalBeanFactory,
MessageSource, ApplicationEventPublisher, ResourcePatternResolver {
/**
* Return the unique id of this application context.
* @return the unique id of the context, or {@code null} if none
*/
@Nullable
String getId();
/**
* Return a name for the deployed application that this context belongs to.
* @return a name for the deployed application, or the empty String by default
*/
String getApplicationName();
/**
* Return a friendly name for this context.
* @return a display name for this context (never {@code null})
*/
String getDisplayName();
/**
* Return the timestamp when this context was first loaded.
* @return the timestamp (ms) when this context was first loaded
*/
long getStartupDate();
/**
* Return the parent context, or {@code null} if there is no parent
* and this is the root of the context hierarchy.
* @return the parent context, or {@code null} if there is no parent
*/
@Nullable
ApplicationContext getParent();
/**
* Expose AutowireCapableBeanFactory functionality for this context.
* <p>This is not typically used by application code, except for the purpose of
* initializing bean instances that live outside of the application context,
* applying the Spring bean lifecycle (fully or partly) to them.
* <p>Alternatively, the internal BeanFactory exposed by the
* {@link ConfigurableApplicationContext} interface offers access to the
* {@link AutowireCapableBeanFactory} interface too. The present method mainly
* serves as a convenient, specific facility on the ApplicationContext interface.
* <p><b>NOTE: As of 4.2, this method will consistently throw IllegalStateException
* after the application context has been closed.</b> In current Spring Framework
* versions, only refreshable application contexts behave that way; as of 4.2,
* all application context implementations will be required to comply.
* @return the AutowireCapableBeanFactory for this context
* @throws IllegalStateException if the context does not support the
* {@link AutowireCapableBeanFactory} interface, or does not hold an
* autowire-capable bean factory yet (e.g. if {@code refresh()} has
* never been called), or if the context has been closed already
* @see ConfigurableApplicationContext#refresh()
* @see ConfigurableApplicationContext#getBeanFactory()
*/
AutowireCapableBeanFactory getAutowireCapableBeanFactory() throws IllegalStateException;
}
ApplicationContext方法属性摘要¶
Java
public interface ApplicationContext extends EnvironmentCapable, ListableBeanFactory, HierarchicalBeanFactory,
MessageSource, ApplicationEventPublisher, ResourcePatternResolver {
@Nullable
String getId();
String getApplicationName();
String getDisplayName();
long getStartupDate();
@Nullable
ApplicationContext getParent();
AutowireCapableBeanFactory getAutowireCapableBeanFactory() throws IllegalStateException;
}
1.5 BeanDefination接口¶
BeanDefination接口定义解析¶
- BeanDefination用于管理Ioc容器中JavaBean与JavaBean之间的依赖关系，其抽象了Java开发人员对于JavaBean的定义
- Spring将开发人员定义的JavaBean的数据结构转化为内存中的BeanDefination数据结构进行维护
完整版源码：¶
Java
/*
* Copyright 2002-2019 the original author or authors.
*
* Licensed under the Apache License, Version 2.0 (the "License");
* you may not use this file except in compliance with the License.
* You may obtain a copy of the License at
*
* https://www.apache.org/licenses/LICENSE-2.0
*
* Unless required by applicable law or agreed to in writing, software
* distributed under the License is distributed on an "AS IS" BASIS,
* WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
* See the License for the specific language governing permissions and
* limitations under the License.
*/
package org.springframework.beans.factory.config;
import org.springframework.beans.BeanMetadataElement;
import org.springframework.beans.MutablePropertyValues;
import org.springframework.core.AttributeAccessor;
import org.springframework.core.ResolvableType;
import org.springframework.lang.Nullable;
/**
* A BeanDefinition describes a bean instance, which has property values,
* constructor argument values, and further information supplied by
* concrete implementations.
*
* <p>This is just a minimal interface: The main intention is to allow a
* {@link BeanFactoryPostProcessor} to introspect and modify property values
* and other bean metadata.
*
* @author Juergen Hoeller
* @author Rob Harrop
* @since 19.03.2004
* @see ConfigurableListableBeanFactory#getBeanDefinition
* @see org.springframework.beans.factory.support.RootBeanDefinition
* @see org.springframework.beans.factory.support.ChildBeanDefinition
*/
public interface BeanDefinition extends AttributeAccessor, BeanMetadataElement {
/**
* Scope identifier for the standard singleton scope: "singleton".
* <p>Note that extended bean factories might support further scopes.
* @see #setScope
*/
String SCOPE_SINGLETON = ConfigurableBeanFactory.SCOPE_SINGLETON;
/**
* Scope identifier for the standard prototype scope: "prototype".
* <p>Note that extended bean factories might support further scopes.
* @see #setScope
*/
String SCOPE_PROTOTYPE = ConfigurableBeanFactory.SCOPE_PROTOTYPE;
/**
* Role hint indicating that a {@code BeanDefinition} is a major part
* of the application. Typically corresponds to a user-defined bean.
*/
int ROLE_APPLICATION = 0;
/**
* Role hint indicating that a {@code BeanDefinition} is a supporting
* part of some larger configuration, typically an outer
* {@link org.springframework.beans.factory.parsing.ComponentDefinition}.
* {@code SUPPORT} beans are considered important enough to be aware
* of when looking more closely at a particular
* {@link org.springframework.beans.factory.parsing.ComponentDefinition},
* but not when looking at the overall configuration of an application.
*/
int ROLE_SUPPORT = 1;
/**
* Role hint indicating that a {@code BeanDefinition} is providing an
* entirely background role and has no relevance to the end-user. This hint is
* used when registering beans that are completely part of the internal workings
* of a {@link org.springframework.beans.factory.parsing.ComponentDefinition}.
*/
int ROLE_INFRASTRUCTURE = 2;
// Modifiable attributes
/**
* Set the name of the parent definition of this bean definition, if any.
*/
void setParentName(@Nullable String parentName);
/**
* Return the name of the parent definition of this bean definition, if any.
*/
@Nullable
String getParentName();
/**
* Specify the bean class name of this bean definition.
* <p>The class name can be modified during bean factory post-processing,
* typically replacing the original class name with a parsed variant of it.
* @see #setParentName
* @see #setFactoryBeanName
* @see #setFactoryMethodName
*/
void setBeanClassName(@Nullable String beanClassName);
/**
* Return the current bean class name of this bean definition.
* <p>Note that this does not have to be the actual class name used at runtime, in
* case of a child definition overriding/inheriting the class name from its parent.
* Also, this may just be the class that a factory method is called on, or it may
* even be empty in case of a factory bean reference that a method is called on.
* Hence, do <i>not</i> consider this to be the definitive bean type at runtime but
* rather only use it for parsing purposes at the individual bean definition level.
* @see #getParentName()
* @see #getFactoryBeanName()
* @see #getFactoryMethodName()
*/
@Nullable
String getBeanClassName();
/**
* Override the target scope of this bean, specifying a new scope name.
* @see #SCOPE_SINGLETON
* @see #SCOPE_PROTOTYPE
*/
void setScope(@Nullable String scope);
/**
* Return the name of the current target scope for this bean,
* or {@code null} if not known yet.
*/
@Nullable
String getScope();
/**
* Set whether this bean should be lazily initialized.
* <p>If {@code false}, the bean will get instantiated on startup by bean
* factories that perform eager initialization of singletons.
*/
void setLazyInit(boolean lazyInit);
/**
* Return whether this bean should be lazily initialized, i.e. not
* eagerly instantiated on startup. Only applicable to a singleton bean.
*/
boolean isLazyInit();
/**
* Set the names of the beans that this bean depends on being initialized.
* The bean factory will guarantee that these beans get initialized first.
*/
void setDependsOn(@Nullable String... dependsOn);
/**
* Return the bean names that this bean depends on.
*/
@Nullable
String[] getDependsOn();
/**
* Set whether this bean is a candidate for getting autowired into some other bean.
* <p>Note that this flag is designed to only affect type-based autowiring.
* It does not affect explicit references by name, which will get resolved even
* if the specified bean is not marked as an autowire candidate. As a consequence,
* autowiring by name will nevertheless inject a bean if the name matches.
*/
void setAutowireCandidate(boolean autowireCandidate);
/**
* Return whether this bean is a candidate for getting autowired into some other bean.
*/
boolean isAutowireCandidate();
/**
* Set whether this bean is a primary autowire candidate.
* <p>If this value is {@code true} for exactly one bean among multiple
* matching candidates, it will serve as a tie-breaker.
*/
void setPrimary(boolean primary);
/**
* Return whether this bean is a primary autowire candidate.
*/
boolean isPrimary();
/**
* Specify the factory bean to use, if any.
* This the name of the bean to call the specified factory method on.
* @see #setFactoryMethodName
*/
void setFactoryBeanName(@Nullable String factoryBeanName);
/**
* Return the factory bean name, if any.
*/
@Nullable
String getFactoryBeanName();
/**
* Specify a factory method, if any. This method will be invoked with
* constructor arguments, or with no arguments if none are specified.
* The method will be invoked on the specified factory bean, if any,
* or otherwise as a static method on the local bean class.
* @see #setFactoryBeanName
* @see #setBeanClassName
*/
void setFactoryMethodName(@Nullable String factoryMethodName);
/**
* Return a factory method, if any.
*/
@Nullable
String getFactoryMethodName();
/**
* Return the constructor argument values for this bean.
* <p>The returned instance can be modified during bean factory post-processing.
* @return the ConstructorArgumentValues object (never {@code null})
*/
ConstructorArgumentValues getConstructorArgumentValues();
/**
* Return if there are constructor argument values defined for this bean.
* @since 5.0.2
*/
default boolean hasConstructorArgumentValues() {
return !getConstructorArgumentValues().isEmpty();
}
/**
* Return the property values to be applied to a new instance of the bean.
* <p>The returned instance can be modified during bean factory post-processing.
* @return the MutablePropertyValues object (never {@code null})
*/
MutablePropertyValues getPropertyValues();
/**
* Return if there are property values values defined for this bean.
* @since 5.0.2
*/
default boolean hasPropertyValues() {
return !getPropertyValues().isEmpty();
}
/**
* Set the name of the initializer method.
* @since 5.1
*/
void setInitMethodName(@Nullable String initMethodName);
/**
* Return the name of the initializer method.
* @since 5.1
*/
@Nullable
String getInitMethodName();
/**
* Set the name of the destroy method.
* @since 5.1
*/
void setDestroyMethodName(@Nullable String destroyMethodName);
/**
* Return the name of the destroy method.
* @since 5.1
*/
@Nullable
String getDestroyMethodName();
/**
* Set the role hint for this {@code BeanDefinition}. The role hint
* provides the frameworks as well as tools with an indication of
* the role and importance of a particular {@code BeanDefinition}.
* @since 5.1
* @see #ROLE_APPLICATION
* @see #ROLE_SUPPORT
* @see #ROLE_INFRASTRUCTURE
*/
void setRole(int role);
/**
* Get the role hint for this {@code BeanDefinition}. The role hint
* provides the frameworks as well as tools with an indication of
* the role and importance of a particular {@code BeanDefinition}.
* @see #ROLE_APPLICATION
* @see #ROLE_SUPPORT
* @see #ROLE_INFRASTRUCTURE
*/
int getRole();
/**
* Set a human-readable description of this bean definition.
* @since 5.1
*/
void setDescription(@Nullable String description);
/**
* Return a human-readable description of this bean definition.
*/
@Nullable
String getDescription();
// Read-only attributes
/**
* Return a resolvable type for this bean definition,
* based on the bean class or other specific metadata.
* <p>This is typically fully resolved on a runtime-merged bean definition
* but not necessarily on a configuration-time definition instance.
* @return the resolvable type (potentially {@link ResolvableType#NONE})
* @since 5.2
* @see ConfigurableBeanFactory#getMergedBeanDefinition
*/
ResolvableType getResolvableType();
/**
* Return whether this a <b>Singleton</b>, with a single, shared instance
* returned on all calls.
* @see #SCOPE_SINGLETON
*/
boolean isSingleton();
/**
* Return whether this a <b>Prototype</b>, with an independent instance
* returned for each call.
* @since 3.0
* @see #SCOPE_PROTOTYPE
*/
boolean isPrototype();
/**
* Return whether this bean is "abstract", that is, not meant to be instantiated.
*/
boolean isAbstract();
/**
* Return a description of the resource that this bean definition
* came from (for the purpose of showing context in case of errors).
*/
@Nullable
String getResourceDescription();
/**
* Return the originating BeanDefinition, or {@code null} if none.
* Allows for retrieving the decorated bean definition, if any.
* <p>Note that this method returns the immediate originator. Iterate through the
* originator chain to find the original BeanDefinition as defined by the user.
*/
@Nullable
BeanDefinition getOriginatingBeanDefinition();
}
BeanDefination方法属性摘要¶
Java
public interface BeanDefinition extends AttributeAccessor, BeanMetadataElement {
String SCOPE_SINGLETON = ConfigurableBeanFactory.SCOPE_SINGLETON;
String SCOPE_PROTOTYPE = ConfigurableBeanFactory.SCOPE_PROTOTYPE;
int ROLE_APPLICATION = 0;
int ROLE_SUPPORT = 1;
// infrastructure
int ROLE_INFRASTRUCTURE = 2;
// Modifiable attributes
void setParentName(@Nullable String parentName);
@Nullable
String getParentName();
void setBeanClassName(@Nullable String beanClassName);
@Nullable
String getBeanClassName();
void setScope(@Nullable String scope);
@Nullable
String getScope();
void setLazyInit(boolean lazyInit);
boolean isLazyInit();
void setDependsOn(@Nullable String... dependsOn);
@Nullable
String[] getDependsOn();
void setAutowireCandidate(boolean autowireCandidate);
boolean isAutowireCandidate();
void setPrimary(boolean primary);
boolean isPrimary();
void setFactoryBeanName(@Nullable String factoryBeanName);
@Nullable
String getFactoryBeanName();
void setFactoryMethodName(@Nullable String factoryMethodName);
@Nullable
String getFactoryMethodName();
ConstructorArgumentValues getConstructorArgumentValues();
default boolean hasConstructorArgumentValues() {
return !getConstructorArgumentValues().isEmpty();
}
MutablePropertyValues getPropertyValues();
default boolean hasPropertyValues() {
return !getPropertyValues().isEmpty();
}
void setInitMethodName(@Nullable String initMethodName);
@Nullable
String getInitMethodName();
void setDestroyMethodName(@Nullable String destroyMethodName);
@Nullable
String getDestroyMethodName();
void setRole(int role);
int getRole();
void setDescription(@Nullable String description);
@Nullable
String getDescription();
// Read-only attributes
ResolvableType getResolvableType();
boolean isSingleton();
boolean isPrototype();
boolean isAbstract();
@Nullable
String getResourceDescription();
@Nullable
BeanDefinition getOriginatingBeanDefinition();
}
// org.springframework.core.AttributeAccessor
package org.springframework.core;
public interface AttributeAccessor {
void setAttribute(String name, @Nullable Object value);
@Nullable
Object getAttribute(String name);
@Nullable
Object removeAttribute(String name);
boolean hasAttribute(String name);
String[] attributeNames();
}
// org.springframework.beans.BeanMetadataElemen
package org.springframework.beans;
public interface BeanMetadataElement {
@Nullable
default Object getSource() {
return null;
}
}
2.从一个Demo程序开始¶
2.1 Demo项目配置¶
maven的pom.xml配置文件¶
XML
<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
<modelVersion>4.0.0</modelVersion>
<!-- <parent>-->
<!-- <groupId>com.acanx</groupId>-->
<!-- <artifactId>ACANX-JavaEE-Dependencies</artifactId>-->
<!-- <version>0.0.1</version>-->
<!-- </parent>-->
<groupId>com.acanx</groupId>
<artifactId>JavaWeb-Spring</artifactId>
<version>0.0.1-SNAPSHOT</version>
<packaging>war</packaging>
<name>JavaWeb-Spring</name>
<description>JavaWeb-Spring project</description>
<properties>
<project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
<project.reporting.outputEncoding>UTF-8</project.reporting.outputEncoding>
<java.version>11</java.version>
<spring.version>5.2.1.RELEASE</spring.version>
<!-- log4j日志文件管理包版本 -->
<slf4j.version>2.0.0-alpha1</slf4j.version>
<logback.version>1.3.0-alpha5</logback.version>
<!-- log4j日志包版本号 -->
<log4j2.version>2.8.2</log4j2.version>
<log4j.version>1.2.17</log4j.version>
<junit.version>4.12</junit.version>
<fastjson.version>1.2.62</fastjson.version>
<maven-compiler-plugin.version>3.8.1</maven-compiler-plugin.version>
</properties>
<dependencies>
<dependency>
<groupId>org.springframework</groupId>
<artifactId>spring-context</artifactId>
<version>${spring.version}</version>
</dependency>
<dependency>
<groupId>ch.qos.logback</groupId>
<artifactId>logback-classic</artifactId>
<version>${logback.version}</version>
</dependency>
<!-- 添加fastjson -->
<dependency>
<groupId>com.alibaba</groupId>
<artifactId>fastjson</artifactId>
<version>${fastjson.version}</version>
</dependency>
<!-- 单元测试-->
<!-- https://mvnrepository.com/artifact/junit/junit -->
<dependency>
<groupId>junit</groupId>
<artifactId>junit</artifactId>
<version>${junit.version}</version>
<scope>test</scope>
</dependency>
</dependencies>
<build>
<plugins>
<plugin>
<groupId>org.apache.maven.plugins</groupId>
<artifactId>maven-compiler-plugin</artifactId>
<version>${maven-compiler-plugin.version}</version>
<configuration>
<target>11</target>
<source>11</source>
</configuration>
</plugin>
</plugins>
</build>
</project>
2.2 Demo程序¶
2.2.1启动类¶
- 代码位置:com.acanx.spring.xml.CspringIocConfigByFileSystemXmlApplicationContext.java
Java
package com.acanx.spring.xml; import com.acanx.spring.bean.Car; import org.apache.commons.logging.Log; import org.apache.commons.logging.LogFactory; import org.slf4j.Logger; import org.slf4j.LoggerFactory; import org.springframework.context.ApplicationContext; import org.springframework.context.support.FileSystemXmlApplicationContext; /** * ACANX-JavaWeb / com.acanx.spring.xml / SpringIocConfigByXmlFileInClassPath.java * 文件由 ACANX 创建于 2019/7/30 - 13:39 * Description SpringIocConfigByXmlFileInClassPath: * 补充说明： 使用FileSystemXmlApplicationContext加载文件系统下的配置文件 * * @author ACANX * @version 0.0.1.0 * @date 2019/7/30 13:39 * @since 0.0.1-SNAPSHOT */ public class CspringIocConfigByFileSystemXmlApplicationContext { private static final Logger logger= LoggerFactory.getLogger(CspringIocConfigByFileSystemXmlApplicationContext.class); public static void main(String[] args) { logger.info("-------------------"); logger.info(System.getProperty("org.apache.commons.logging.LogFactory")); logger.info(System.getProperty("org.apache.commons.logging.Log")); logger.info("-------------------"); String location="D:\\ProgramCode\\JavaCode\\ACANX-JavaWeb\\JavaWeb-Spring\\ApplicationContextC.xml"; ApplicationContext applicationContext = new FileSystemXmlApplicationContext(location); Car car = (Car) applicationContext.getBean("myCar"); logger.info(car.toString()); logger.info("Info :{}",logger.isInfoEnabled()); String[] beanNames=applicationContext.getBeanDefinitionNames(); for (String beanName:beanNames) { logger.info(beanName+"::::: "+applicationContext.getBean(beanName).toString()); } } }
2.2.2使用到的Bena对象¶
Java
package com.acanx.spring.bean;
public class Car {
private String name;
private String price;
// get set 默认构造方法已省略
}
2.2.3 springContext的xml文件ApplicationContextC.xml¶
XML
<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd">
<bean name="myCar" class="com.acanx.spring.bean.Car" >
<property name="name" value="QQAI"/>
<property name="price" value="2222"/>
</bean>
</beans>
2.2.4 配置日志 logback.xml（resources文件夹下）¶
XML
<?xml version="1.0" encoding="UTF-8"?>
<configuration scan="true" scanPeriod="60 seconds" debug="false">
<property name="LOG_PATH" value=".log"/>
<property name="APP_NAME" value="IOCDemo"/>
<!--设置系统日志目录-->
<property name="APP_DIR" value="app-IOCDemo"/>
<property name="CONSOLE_LOG_PATTERN" value="[CLP]${CONSOLE_LOG_PATTERN:-%clr(%d{${LOG_DATEFORMAT_PATTERN:-yyyy-MM-dd HH:mm:ss.SSS}}){faint} %clr(${LOG_LEVEL_PATTERN:-%5p}) %clr(${PID:- }){magenta} %clr(---){faint} %clr([%15.15t]){faint} %clr(%-40.40logger{39}){cyan} %clr(%-15.15method){cyan} %clr([%4.4line{4}]){magenta} %clr(:){faint} %m%n${LOG_EXCEPTION_CONVERSION_WORD:-%wEx}}"/>
<property name="FILE_LOG_PATTERN" value="${FILE_LOG_PATTERN:-%d{${LOG_DATEFORMAT_PATTERN:-yyyy-MM-dd HH:mm:ss.SSS}} ${LOG_LEVEL_PATTERN:-%5p} ${PID:- } --- [%t] %-40.40logger{39} : %m%n${LOG_EXCEPTION_CONVERSION_WORD:-%wEx}}"/>
<property name="CONSOLE_LOGBACK_PATTERN" value="[控制台] %d{yyyy-MM-dd HH:mm:ss.SSS} [%thread] %-5level | %-80logger # %-40M [%4line] : %msg%n"/>
<contextName>logback</contextName>
<!--输出到控制台-->
<appender name="CONSOLE" class="ch.qos.logback.core.ConsoleAppender">
<filter class="ch.qos.logback.classic.filter.ThresholdFilter">
<level>TRACE</level>
</filter>
<layout class="ch.qos.logback.classic.PatternLayout">
<Pattern>${CONSOLE_LOGBACK_PATTERN}</Pattern>
</layout>
<encoder>
<!-- 文件名 [%file]-->
<pattern>${CONSOLE_LOGBACK_PATTERN}</pattern>
</encoder>
</appender>
<appender name="ERROR_FILE" class="ch.qos.logback.core.rolling.RollingFileAppender">
<filter class="ch.qos.logback.classic.filter.ThresholdFilter">
<level>ERROR</level>
<onMatch>ACCEPT</onMatch>
<onMismatch>DENY</onMismatch>
</filter>
<File>.log/ACANX-JavaWeb/LOG-ERROR.log</File>
<rollingPolicy class="ch.qos.logback.core.rolling.TimeBasedRollingPolicy">
<fileNamePattern>.log/server-error-%d{yyyyMMdd}.log.%i
</fileNamePattern>
<timeBasedFileNamingAndTriggeringPolicy class="ch.qos.logback.core.rolling.SizeAndTimeBasedFNATP">
<maxFileSize>5MB</maxFileSize>
</timeBasedFileNamingAndTriggeringPolicy>
<maxHistory>2</maxHistory>
</rollingPolicy>
<layout class="ch.qos.logback.classic.PatternLayout">
<Pattern>${CONSOLE_LOGBACK_PATTERN}</Pattern>
</layout>
</appender>
<appender name="WARN_FILE" class="ch.qos.logback.core.rolling.RollingFileAppender">
<filter class="ch.qos.logback.classic.filter.ThresholdFilter">
<level>WARN</level>
<onMatch>ACCEPT</onMatch>
<onMismatch>DENY</onMismatch>
</filter>
<File>.log/ACANX-JavaWeb/LOG-WARN.log</File>
<rollingPolicy class="ch.qos.logback.core.rolling.TimeBasedRollingPolicy">
<fileNamePattern>.log/ACANX-JavaWeb/server-WARN-%d{yyyyMMdd}.log.%i
</fileNamePattern>
<timeBasedFileNamingAndTriggeringPolicy class="ch.qos.logback.core.rolling.SizeAndTimeBasedFNATP">
<maxFileSize>5MB</maxFileSize>
</timeBasedFileNamingAndTriggeringPolicy>
<maxHistory>2</maxHistory>
</rollingPolicy>
<layout class="ch.qos.logback.classic.PatternLayout">
<Pattern>${CONSOLE_LOGBACK_PATTERN}</Pattern>
</layout>
</appender>
<appender name="INFO_FILE" class="ch.qos.logback.core.rolling.RollingFileAppender">
<File>.log/ACANX-JavaWeb/LOG-INFO.log</File>
<filter class="ch.qos.logback.classic.filter.ThresholdFilter">
<level>INFO</level>
<onMatch>ACCEPT</onMatch>
<onMismatch>DENY</onMismatch>
</filter>
<rollingPolicy class="ch.qos.logback.core.rolling.TimeBasedRollingPolicy">
<fileNamePattern>.log/ACANX-JavaWeb/server-info-%d{yyyyMMdd}.log.%i</fileNamePattern>
<timeBasedFileNamingAndTriggeringPolicy class="ch.qos.logback.core.rolling.SizeAndTimeBasedFNATP">
<maxFileSize>5MB</maxFileSize>
</timeBasedFileNamingAndTriggeringPolicy>
<maxHistory>2</maxHistory>
</rollingPolicy>
<layout class="ch.qos.logback.classic.PatternLayout">
<Pattern>${CONSOLE_LOGBACK_PATTERN}</Pattern>
</layout>
<encoder class="ch.qos.logback.classic.encoder.PatternLayoutEncoder">
<!--格式化输出：%d表示日期，%thread表示线程名，%-5level：级别从左显示5个字符宽度%msg：日志消息，%n是换行符-->
<pattern>${CONSOLE_LOGBACK_PATTERN}</pattern>
</encoder>
</appender>
<appender name="TRACE_FILE" class="ch.qos.logback.core.rolling.RollingFileAppender">
<filter class="ch.qos.logback.classic.filter.ThresholdFilter">
<level>TRACE</level>
<onMatch>ACCEPT</onMatch>
<onMismatch>DENY</onMismatch>
</filter>
<File>.log/ACANX-JavaWeb/LOG-TRACE.log</File>
<rollingPolicy class="ch.qos.logback.core.rolling.TimeBasedRollingPolicy">
<fileNamePattern>.log/ACANX-JavaWeb/server-TRACE-%d{yyyyMMdd}.log.%i
</fileNamePattern>
<timeBasedFileNamingAndTriggeringPolicy class="ch.qos.logback.core.rolling.SizeAndTimeBasedFNATP">
<maxFileSize>5MB</maxFileSize>
</timeBasedFileNamingAndTriggeringPolicy>
<maxHistory>2</maxHistory>
</rollingPolicy>
<layout class="ch.qos.logback.classic.PatternLayout">
<Pattern>${CONSOLE_LOGBACK_PATTERN}</Pattern>
</layout>
</appender>
<appender name="FULL_LEVEL_FILE" class="ch.qos.logback.core.rolling.RollingFileAppender">
<File>.log/ACANX-JavaWeb/LOG-FULL.log</File>
<filter class="ch.qos.logback.classic.filter.ThresholdFilter">
<level>TRACE</level>
</filter>
<encoder>
<!-- 文件名 [%file] -->
<pattern>${CONSOLE_LOGBACK_PATTERN}</pattern>
</encoder>
<rollingPolicy class="ch.qos.logback.core.rolling.TimeBasedRollingPolicy">
<fileNamePattern>.log/ACANX-JavaWeb/LOG-FULL-%d{yyyyMMdd}.log.%i</fileNamePattern>
<timeBasedFileNamingAndTriggeringPolicy class="ch.qos.logback.core.rolling.SizeAndTimeBasedFNATP">
<maxFileSize>5MB</maxFileSize>
</timeBasedFileNamingAndTriggeringPolicy>
<maxHistory>2</maxHistory>
</rollingPolicy>
<layout class="ch.qos.logback.classic.PatternLayout">
<Pattern>${CONSOLE_LOGBACK_PATTERN}</Pattern>
</layout>
</appender>
<root level="TRACE" additivity="true">
<appender-ref ref="CONSOLE"/>
<appender-ref ref="WARN_FILE"/>
<appender-ref ref="ERROR_FILE"/>
<appender-ref ref="INFO_FILE"/>
<appender-ref ref="TRACE_FILE"/>
<appender-ref ref="FULL_LEVEL_FILE"/>
</root>
<!-- TRACE, DEBUG, INFO, WARN, ERROR, ALL 和 OFF -->
<logger name="org" level="TRACE" additivity="true"></logger>
<logger name="org.springframework.context" level="TRACE" additivity="false"></logger>
<logger name="org.apache" level="TRACE"/>
<logger name="com.alibaba" level="TRACE"/>
<!-- 如果这里设置了additivity=true 代码打印信息向上传递,将打印信息传递到root ，并且自己的appender-ref 也会打印，这样就是打印了俩次日志-->
</configuration>
3.Spring IOC容器的创建¶
3.1 进入FileSystemXmlApplicationContext（AbstractXmlApplicationContext抽象类的具体实现类）¶
- 代码位置: org.springframework.context.support.FileSystemXmlApplicationContext.java
Java
public FileSystemXmlApplicationContext(String configLocation) throws BeansException { this(new String[] {configLocation}, true, null); } // 上面的this 来到下面的重载构造方法 public FileSystemXmlApplicationContext( String[] configLocations, boolean refresh, @Nullable ApplicationContext parent) throws BeansException { super(parent); // 初始化父容器AbstractApplicationContext setConfigLocations(configLocations); // 设置资源文件的位置 if (refresh) { refresh();// 核心方法，具体定义在超类AbstractApplicationContext（抽象类）中，是一个模板方法 } }
3.2 初始化父容器AbstractApplicationContext¶
3.2.1 AbstractXmlApplicationContext抽象类（FileSystemXmlApplicationContext的父类）¶
- 代码位置: org.springframework.context.support.AbstractXmlApplicationContext.java
3.2.2 AbstractRefreshableConfigApplicationContext抽象类（ AbstractXmlApplicationContext的父类）¶
- 代码位置:org.springframework.context.support.AbstractRefreshableConfigApplicationContext.java
3.2.3 AbstractRefreshableApplicationContext抽象类¶
- 代码位置:org.springframework.context.support.AbstractRefreshableApplicationContext.java
3.2.4 AbstractApplicationContext抽象类¶
- 代码位置:org.springframework.context.support.AbstractApplicationContext.java
Java
public AbstractApplicationContext(@Nullable ApplicationContext parent) { this(); setParent(parent); } //上面对应的this()方法 public AbstractApplicationContext() { this.resourcePatternResolver = getResourcePatternResolver(); } //上面对应的 getResourcePatternResolver()方法 protected ResourcePatternResolver getResourcePatternResolver() { return new PathMatchingResourcePatternResolver(this); } // this()之后的setParent(parent);方法 @Override public void setParent(@Nullable ApplicationContext parent) { this.parent = parent; if (parent != null) { Environment parentEnvironment = parent.getEnvironment(); if (parentEnvironment instanceof ConfigurableEnvironment) { getEnvironment().merge((ConfigurableEnvironment) parentEnvironment); } } }
3.5 PathMatchingResourcePatternResolver类¶
- PathMatchingResourcePatternResolver(this)对应的构造方法
- 代码位置:org.springframework.core.io.support.PathMatchingResourcePatternResolver.java
4.setConfigLocations(String... locations) 方法¶
- 设置资源文件的位置
4.1 AbstractRefreshableConfigApplicationContext.setConfigLocations(@Nullable String... locations) 方法¶
- 代码位置:org.springframework.context.support.AbstractRefreshableConfigApplicationContext.java
Java
public void setConfigLocations(@Nullable String... locations) { if (locations != null) { Assert.noNullElements(locations, "Config locations must not be null"); this.configLocations = new String[locations.length]; for (int i = 0; i < locations.length; i++) { this.configLocations[i] = resolvePath(locations[i]).trim(); } } else { this.configLocations = null; } }
5. refresh()方法¶
- AbstractApplicationContext抽象类中定义的refresh()模板方法
- 定义了需要执行刷新操作的一些步骤，只是一个模板，个性化的逻辑由其子类来具体实现
5.1 refresh()方法定义¶
- 代码位置:org.springframework.context.support.AbstractApplicationContext.java
Java
@Override public void refresh() throws BeansException, IllegalStateException { synchronized (this.startupShutdownMonitor) { // Prepare this context for refreshing. prepareRefresh(); // Tell the subclass to refresh the internal bean factory. // 创建BeanFactory ConfigurableListableBeanFactory beanFactory = obtainFreshBeanFactory(); // Prepare the bean factory for use in this context. prepareBeanFactory(beanFactory); try { // Allows post-processing of the bean factory in context subclasses. postProcessBeanFactory(beanFactory); // Invoke factory processors registered as beans in the context. invokeBeanFactoryPostProcessors(beanFactory); // Register bean processors that intercept bean creation. registerBeanPostProcessors(beanFactory); // Initialize message source for this context. initMessageSource(); // Initialize event multicaster for this context. initApplicationEventMulticaster(); // Initialize other special beans in specific context subclasses. onRefresh(); // Check for listener beans and register them. registerListeners(); // Instantiate all remaining (non-lazy-init) singletons. // 实例化Bean finishBeanFactoryInitialization(beanFactory); // Last step: publish corresponding event. finishRefresh(); } catch (BeansException ex) { if (logger.isWarnEnabled()) { logger.warn("Exception encountered during context initialization - " + "cancelling refresh attempt: " + ex); } // Destroy already created singletons to avoid dangling resources. destroyBeans(); // Reset 'active' flag. cancelRefresh(ex); // Propagate exception to caller. throw ex; } finally { // Reset common introspection caches in Spring's core, since we // might not ever need metadata for singleton beans anymore... resetCommonCaches(); } } }
5.2 prepareRefresh()方法¶
- 正式Refresh()操作前的准备工作
- 代码位置:org.springframework.context.support.AbstractApplicationContext.java
Java
protected void prepareRefresh() { // Switch to active. this.startupDate = System.currentTimeMillis(); this.closed.set(false); this.active.set(true); if (logger.isDebugEnabled()) { if (logger.isTraceEnabled()) { logger.trace("Refreshing " + this); } else { logger.debug("Refreshing " + getDisplayName()); } } // Initialize any placeholder property sources in the context environment. initPropertySources(); // Validate that all properties marked as required are resolvable: // see ConfigurablePropertyResolver#setRequiredProperties getEnvironment().validateRequiredProperties(); // Store pre-refresh ApplicationListeners... if (this.earlyApplicationListeners == null) { this.earlyApplicationListeners = new LinkedHashSet<>(this.applicationListeners); } else { // Reset local application listeners to pre-refresh state. this.applicationListeners.clear(); this.applicationListeners.addAll(this.earlyApplicationListeners); } // Allow for the collection of early ApplicationEvents, // to be published once the multicaster is available... this.earlyApplicationEvents = new LinkedHashSet<>(); } // 上述定义的initPropertySources()方法，具体由子类实现 protected void initPropertySources() { // For subclasses: do nothing by default. }
5.3 obtainFreshBeanFactory()方法¶
- 创建BeanFactory的核心方法
- 代码位置:org.springframework.context.support.AbstractApplicationContext.java
Java
protected ConfigurableListableBeanFactory obtainFreshBeanFactory() { refreshBeanFactory();// 刷新BeanFactory，抽象方法由其子类实现,5.3.1中有说明 return getBeanFactory();// 获取BeanFactory，父类的抽象方法继承并由其子类实现 } protected abstract void refreshBeanFactory() throws BeansException, IllegalStateException; @Override // 该方法在ConfigurableApplicationContext接口中定义 public abstract ConfigurableListableBeanFactory getBeanFactory() throws IllegalStateException;
5.3.1 refreshBeanFactory()方法的一种实现¶
- org.springframework.context.support.AbstractRefreshableApplicationContext中的具体实现如下
- refreshBeanFactory()方法是AbstractApplicationContext中定义的抽象方法
- AbstractRefreshableApplicationContext中的refreshBeanFactory()方法是该抽象方法的一个具体实现
- 主要作用：刷新BeanFactory
Java
// AbstractRefreshableApplicationContext中refreshBeanFactory()方法的一种实现 @Override protected final void refreshBeanFactory() throws BeansException { // 检查上下文中是否已存在BeanFactory if (hasBeanFactory()) { // 存在BeanFactory时先销毁已存在的BeanFactory destroyBeans();//调用AbstractApplicationContext中的实现 /** * 以下是AbstractApplicationContext中destroyBeans()方法的实现 * protected void destroyBeans() { * getBeanFactory().destroySingletons(); * } */ closeBeanFactory();// 调用本抽象类中的closeBeanFactory()方法，具体代码在下面列出 } try { // 创建新的BeanFactory // 下面这行代码只会创建一个空的BeanFactory，并未有任何Bean DefaultListableBeanFactory beanFactory = createBeanFactory(); beanFactory.setSerializationId(getId()); customizeBeanFactory(beanFactory); loadBeanDefinitions(beanFactory);// refreshBeanFactory()方法实现的核心 synchronized (this.beanFactoryMonitor) { this.beanFactory = beanFactory; } } catch (IOException ex) { throw new ApplicationContextException("I/O error parsing bean definition source for " + getDisplayName(), ex); } } // AbstractRefreshableApplicationContext抽象类中refreshBeanFactory()方法内调用的closeBeanFactory()方法 @Override protected final void closeBeanFactory() { synchronized (this.beanFactoryMonitor) { if (this.beanFactory != null) { //销毁已存在的BeanFactory this.beanFactory.setSerializationId(null); this.beanFactory = null; } } } //AbstractRefreshableApplicationContext抽象类中refreshBeanFactory()方法内调用createBeanFactory()方法 protected DefaultListableBeanFactory createBeanFactory() { // 调用下面 AbstractApplicationContext中的getInternalParentBeanFactory()方法 return new DefaultListableBeanFactory(getInternalParentBeanFactory()); }
AbstractApplicationContext中的getInternalParentBeanFactory()方法¶
Java
@Nullable
protected BeanFactory getInternalParentBeanFactory() {
return (getParent() instanceof ConfigurableApplicationContext ?
((ConfigurableApplicationContext) getParent()).getBeanFactory() : getParent());
}
DefaultListableBeanFactory的构造方法¶
Java
public DefaultListableBeanFactory(@Nullable BeanFactory parentBeanFactory) {
super(parentBeanFactory);// 调用AbstractAutowireCapableBeanFactory(抽象类)的构造方法
}
DefaultListableBeanFactory父类AbstractAutowireCapableBeanFactory(抽象类)的构造方法¶
Java
public AbstractAutowireCapableBeanFactory(@Nullable BeanFactory parentBeanFactory) {
this();
setParentBeanFactory(parentBeanFactory);
}
AbstractRefreshableApplicationContext中的customizeBeanFactory(beanFactory)方法¶
Java
protected void customizeBeanFactory(DefaultListableBeanFactory beanFactory) {
if (this.allowBeanDefinitionOverriding != null) {
beanFactory.setAllowBeanDefinitionOverriding(this.allowBeanDefinitionOverriding);
}
if (this.allowCircularReferences != null) {
beanFactory.setAllowCircularReferences(this.allowCircularReferences);
}
}
AbstractRefreshableApplicationContext中的loadBeanDefinitions(beanFactory)方法¶
- 是实现refreshBeanFactory()方法的核心
- org.springframework.context.support.AbstractRefreshableApplicationContext中定义的抽象方法
- 该抽象方法的一个具体实现在org.springframework.context.support.AbstractXmlApplicationContext中
org.springframework.context.support.AbstractXmlApplicationContext中的loadBeanDefinitions(DefaultListableBeanFactory beanFactory)方法¶
- org.springframework.context.support.AbstractRefreshableApplicationContext中定义的抽象方法loadBeanDefinitions(DefaultListableBeanFactory beanFactory)的一个实现
Java
@Override protected void loadBeanDefinitions(DefaultListableBeanFactory beanFactory) throws BeansException, IOException { // Create a new XmlBeanDefinitionReader for the given BeanFactory. // 通过上一步创建的空BeanFactory来创建新的XmlBeanDefinitionReader对象 // XmlBeanDefinitionReader用于解析xml文件中定义的bean XmlBeanDefinitionReader beanDefinitionReader = new XmlBeanDefinitionReader(beanFactory); // // Configure the bean definition reader with this context's // resource loading environment. beanDefinitionReader.setEnvironment(this.getEnvironment()); beanDefinitionReader.setResourceLoader(this); beanDefinitionReader.setEntityResolver(new ResourceEntityResolver(this)); // Allow a subclass to provide custom initialization of the reader, // then proceed with actually loading the bean definitions. initBeanDefinitionReader(beanDefinitionReader); loadBeanDefinitions(beanDefinitionReader); //这是一个重载方法，入参是上面生成的beanDefinitionReader }
new XmlBeanDefinitionReader(beanFactory)¶
- XmlBeanDefinitionReader(beanFactory)构造方法调用其父类AbstractBeanDefinitionReader的构造方法，具体如下
Java
protected AbstractBeanDefinitionReader(BeanDefinitionRegistry registry) { Assert.notNull(registry, "BeanDefinitionRegistry must not be null"); this.registry = registry; // Determine ResourceLoader to use. if (this.registry instanceof ResourceLoader) { this.resourceLoader = (ResourceLoader) this.registry; } else { this.resourceLoader = new PathMatchingResourcePatternResolver(); } // Inherit Environment if possible if (this.registry instanceof EnvironmentCapable) { this.environment = ((EnvironmentCapable) this.registry).getEnvironment(); } else { this.environment = new StandardEnvironment(); } }
AbstractXmlApplicationContext抽象类中的initBeanDefinitionReader(beanDefinitionReader)方法¶
Java
protected void initBeanDefinitionReader(XmlBeanDefinitionReader reader) {
reader.setValidating(this.validating);
}
AbstractXmlApplicationContext抽象类中的loadBeanDefinitions(XmlBeanDefinitionReader reader)方法¶
- 主要功能是解析资源文件的位置
- 调用XmlBeanDefinitionReader对象的loadBeanDefinitions方法解析bean的定义
Java
protected void loadBeanDefinitions(XmlBeanDefinitionReader reader) throws BeansException, IOException { Resource[] configResources = getConfigResources(); if (configResources != null) { reader.loadBeanDefinitions(configResources); //具体调用AbstractBeanDefinitionReader中实现的loadBeanDefinitions(Resource... resources)方法 } String[] configLocations = getConfigLocations(); if (configLocations != null) { reader.loadBeanDefinitions(configLocations);//具体调用AbstractBeanDefinitionReader中实现的loadBeanDefinitions(String... locations) } }
reader.loadBeanDefinitions(configResources)方法与reader.loadBeanDefinitions(configLocations)方法¶
- XmlBeanDefinitionReader对象的loadBeanDefinitions方法用于解析bean的定义
- reader是XmlBeanDefinitionReader类型的对象，loadBeanDefinitions方法定义在BeanDefinitionReader接口中，
- loadBeanDefinitions方法具体是在AbstractBeanDefinitionReader抽象类中实现的，具体代码如下：
Java
@Override public int loadBeanDefinitions(Resource... resources) throws BeanDefinitionStoreException { Assert.notNull(resources, "Resource array must not be null"); int count = 0; // 遍历每一个资源并依次调用重载方法loadBeanDefinitions(Resource resource)，定义在XmlBeanDefinitionReader中，具体实现在XmlBeanDefinitionReader中 for (Resource resource : resources) { count += loadBeanDefinitions(resource);// } return count; } @Override public int loadBeanDefinitions(String... locations) throws BeanDefinitionStoreException { Assert.notNull(locations, "Location array must not be null"); int count = 0; //遍历资源数组，调用重载方法loadBeanDefinitions(String location) for (String location : locations) { count += loadBeanDefinitions(location);// } return count; }
count += loadBeanDefinitions(resource)中的loadBeanDefinitions(resource)方法¶
- loadBeanDefinitions(resource)方法在BeanDefinitionReader接口中定义，具体实现是在XmlBeanDefinitionReader中
- XmlBeanDefinitionReader中的实现代码如下：
- 可以看到，上面的方法又调用了loadBeanDefinitions(new EncodedResource(resource))方法，该方法在BeanDefinitionReader接口中定义，具体实现在XmlBeanDefinitionReader中,具体实现，详细代码如下：
Java
public int loadBeanDefinitions(EncodedResource encodedResource) throws BeanDefinitionStoreException { Assert.notNull(encodedResource, "EncodedResource must not be null"); if (logger.isTraceEnabled()) { logger.trace("Loading XML bean definitions from " + encodedResource); } Set<EncodedResource> currentResources = this.resourcesCurrentlyBeingLoaded.get(); if (currentResources == null) { currentResources = new HashSet<>(4); this.resourcesCurrentlyBeingLoaded.set(currentResources); } if (!currentResources.add(encodedResource)) { throw new BeanDefinitionStoreException("Detected cyclic loading of " + encodedResource + " - check your import definitions!"); } try { //以流的形式读取资源文件 InputStream inputStream = encodedResource.getResource().getInputStream(); try { InputSource inputSource = new InputSource(inputStream); if (encodedResource.getEncoding() != null) { inputSource.setEncoding(encodedResource.getEncoding()); } // 调用doLoadBeanDefinitions解析载入文件中的bean定义 return doLoadBeanDefinitions(inputSource, encodedResource.getResource()); } finally { inputStream.close(); } } catch (IOException ex) { throw new BeanDefinitionStoreException( "IOException parsing XML document from " + encodedResource.getResource(), ex); } finally { currentResources.remove(encodedResource); if (currentResources.isEmpty()) { this.resourcesCurrentlyBeingLoaded.remove(); } } }
count += loadBeanDefinitions(location)中的loadBeanDefinitions(location)方法¶
- loadBeanDefinitions(location)方法的具体实现AbstractBeanDefinitionReader中；
- 解析资源文件的路径，得到Resource[]资源数组
- 上面AbstractBeanDefinitionReader中的loadBeanDefinitions(String location)方法又调用了同类里面的一个重载方法loadBeanDefinitions(String location, @Nullable Set
actualResources) 具体实现如下： Javapublic int loadBeanDefinitions(String location, @Nullable Set<Resource> actualResources) throws BeanDefinitionStoreException { ResourceLoader resourceLoader = getResourceLoader(); if (resourceLoader == null) { throw new BeanDefinitionStoreException( "Cannot load bean definitions from location [" + location + "]: no ResourceLoader available"); } if (resourceLoader instanceof ResourcePatternResolver) { // Resource pattern matching available. try { Resource[] resources = ((ResourcePatternResolver) resourceLoader).getResources(location); //下一行的核心逻辑 调用上面提到的重载方法loadBeanDefinitions(Resource resource) int count = loadBeanDefinitions(resources); if (actualResources != null) { Collections.addAll(actualResources, resources); } if (logger.isTraceEnabled()) { logger.trace("Loaded " + count + " bean definitions from location pattern [" + location + "]"); } return count; } catch (IOException ex) { throw new BeanDefinitionStoreException( "Could not resolve bean definition resource pattern [" + location + "]", ex); } } else { // Can only load single resources by absolute URL. Resource resource = resourceLoader.getResource(location); int count = loadBeanDefinitions(resource); if (actualResources != null) { actualResources.add(resource); } if (logger.isTraceEnabled()) { logger.trace("Loaded " + count + " bean definitions from location [" + location + "]"); } return count; } }
XmlBeanDefinitionReader类中的doLoadBeanDefinitions(InputSource inputSource, Resource resource)方法¶
- 该方法是载入定义bean的核心方法
- 代码位置：org.springframework.beans.factory.xml.XmlBeanDefinitionReader
Java
protected int doLoadBeanDefinitions(InputSource inputSource, Resource resource) throws BeanDefinitionStoreException { try { // 解析XML文档 Document doc = doLoadDocument(inputSource, resource); // 下面一行代码 注册Bean int count = registerBeanDefinitions(doc, resource); if (logger.isDebugEnabled()) { logger.debug("Loaded " + count + " bean definitions from " + resource); } return count; } catch (BeanDefinitionStoreException ex) { throw ex; } catch (SAXParseException ex) { throw new XmlBeanDefinitionStoreException(resource.getDescription(), "Line " + ex.getLineNumber() + " in XML document from " + resource + " is invalid", ex); } catch (SAXException ex) { throw new XmlBeanDefinitionStoreException(resource.getDescription(), "XML document from " + resource + " is invalid", ex); } catch (ParserConfigurationException ex) { throw new BeanDefinitionStoreException(resource.getDescription(), "Parser configuration exception parsing XML from " + resource, ex); } catch (IOException ex) { throw new BeanDefinitionStoreException(resource.getDescription(), "IOException parsing XML document from " + resource, ex); } catch (Throwable ex) { throw new BeanDefinitionStoreException(resource.getDescription(), "Unexpected exception parsing XML document from " + resource, ex); } } // 注册Bean的方法 public int registerBeanDefinitions(Document doc, Resource resource) throws BeanDefinitionStoreException { BeanDefinitionDocumentReader documentReader = createBeanDefinitionDocumentReader(); int countBefore = getRegistry().getBeanDefinitionCount(); // 注册bean的核心逻辑 documentReader.registerBeanDefinitions(doc, createReaderContext(resource)); return getRegistry().getBeanDefinitionCount() - countBefore; }
DefaultBeanDefinitionDocumentReader.registerBeanDefinitions(Document doc, XmlReaderContext readerContext)¶
- 功能：
- 代码位置：org.springframework.beans.factory.xml.DefaultBeanDefinitionDocumentReader
Java
@Override public void registerBeanDefinitions(Document doc, XmlReaderContext readerContext) { this.readerContext = readerContext; // 核心逻辑 doRegisterBeanDefinitions(doc.getDocumentElement()); } // registerBeanDefinitions方法中调用的doRegisterBeanDefinitions方法 @SuppressWarnings("deprecation") // for Environment.acceptsProfiles(String...) protected void doRegisterBeanDefinitions(Element root) { // Any nested <beans> elements will cause recursion in this method. In // order to propagate and preserve <beans> default-* attributes correctly, // keep track of the current (parent) delegate, which may be null. Create // the new (child) delegate with a reference to the parent for fallback purposes, // then ultimately reset this.delegate back to its original (parent) reference. // this behavior emulates a stack of delegates without actually necessitating one. BeanDefinitionParserDelegate parent = this.delegate; this.delegate = createDelegate(getReaderContext(), root, parent); if (this.delegate.isDefaultNamespace(root)) { String profileSpec = root.getAttribute(PROFILE_ATTRIBUTE); if (StringUtils.hasText(profileSpec)) { String[] specifiedProfiles = StringUtils.tokenizeToStringArray( profileSpec, BeanDefinitionParserDelegate.MULTI_VALUE_ATTRIBUTE_DELIMITERS); // We cannot use Profiles.of(...) since profile expressions are not supported // in XML config. See SPR-12458 for details. if (!getReaderContext().getEnvironment().acceptsProfiles(specifiedProfiles)) { if (logger.isDebugEnabled()) { logger.debug("Skipped XML bean definition file due to specified profiles [" + profileSpec + "] not matching: " + getReaderContext().getResource()); } return; } } } preProcessXml(root); // 核心逻辑 parseBeanDefinitions(root, this.delegate); postProcessXml(root); this.delegate = parent; } // 上面方法中调用的parseBeanDefinitions(root, this.delegate)对应的方法实现 protected void parseBeanDefinitions(Element root, BeanDefinitionParserDelegate delegate) { if (delegate.isDefaultNamespace(root)) { NodeList nl = root.getChildNodes(); for (int i = 0; i < nl.getLength(); i++) { Node node = nl.item(i); if (node instanceof Element) { Element ele = (Element) node; if (delegate.isDefaultNamespace(ele)) { // 本方法的核心逻辑 parseDefaultElement(ele, delegate); } else { delegate.parseCustomElement(ele); } } } } else { delegate.parseCustomElement(root); } } // 上述方法调用的parseDefaultElement(ele, delegate);的具体实现 // 根据bean配置的不同，进入不同分支 private void parseDefaultElement(Element ele, BeanDefinitionParserDelegate delegate) { if (delegate.nodeNameEquals(ele, IMPORT_ELEMENT)) { importBeanDefinitionResource(ele); } else if (delegate.nodeNameEquals(ele, ALIAS_ELEMENT)) { processAliasRegistration(ele); } else if (delegate.nodeNameEquals(ele, BEAN_ELEMENT)) { // 本文示例会进入该方法 processBeanDefinition(ele, delegate); } else if (delegate.nodeNameEquals(ele, NESTED_BEANS_ELEMENT)) { // recurse doRegisterBeanDefinitions(ele); } } // 上述方法最后进入processBeanDefinition(ele, delegate)后的处理过程： protected void processBeanDefinition(Element ele, BeanDefinitionParserDelegate delegate) { BeanDefinitionHolder bdHolder = delegate.parseBeanDefinitionElement(ele); if (bdHolder != null) { bdHolder = delegate.decorateBeanDefinitionIfRequired(ele, bdHolder); try { // Register the final decorated instance. // 注册Bean的关键代码 BeanDefinitionReaderUtils.registerBeanDefinition(bdHolder, getReaderContext().getRegistry()); } catch (BeanDefinitionStoreException ex) { getReaderContext().error("Failed to register bean definition with name '" + bdHolder.getBeanName() + "'", ele, ex); } // Send registration event. getReaderContext().fireComponentRegistered(new BeanComponentDefinition(bdHolder)); } }
BeanDefinitionReaderUtils的registerBeanDefinition(bdHolder, getReaderContext().getRegistry())方法¶
- 主要作用：
- 代码位置：org.springframework.beans.factory.support.BeanDefinitionReaderUtils
Java
public static void registerBeanDefinition( BeanDefinitionHolder definitionHolder, BeanDefinitionRegistry registry) throws BeanDefinitionStoreException { // Register bean definition under primary name. String beanName = definitionHolder.getBeanName(); // 将Bean的名字和BeanDefinition对象进行注册 // registerBeanDefinition(beanName, definitionHolder.getBeanDefinition());方法定义在BeanDefinitionRegistry接口中： // 具体实现在中实现 registry.registerBeanDefinition(beanName, definitionHolder.getBeanDefinition()); // Register aliases for bean name, if any. String[] aliases = definitionHolder.getAliases(); if (aliases != null) { for (String alias : aliases) { registry.registerAlias(beanName, alias); } } }
DefaultListableBeanFactory中registerBeanDefinition(String beanName, BeanDefinition beanDefinition)¶
- 作用：
- DefaultListableBeanFactory的字段beanDefinitionMap是一个ConcurrentHashMap
- DefaultListableBeanFactory的字段beanDefinitionNames是一个ArrayList
类型数据，用于存储Bean的名称 -
代码位置：org.springframework.beans.factory.support.DefaultListableBeanFactory¶
Java@Override public void registerBeanDefinition(String beanName, BeanDefinition beanDefinition) throws BeanDefinitionStoreException { Assert.hasText(beanName, "Bean name must not be empty"); Assert.notNull(beanDefinition, "BeanDefinition must not be null"); if (beanDefinition instanceof AbstractBeanDefinition) { try { ((AbstractBeanDefinition) beanDefinition).validate(); } catch (BeanDefinitionValidationException ex) { throw new BeanDefinitionStoreException(beanDefinition.getResourceDescription(), beanName, "Validation of bean definition failed", ex); } } BeanDefinition existingDefinition = this.beanDefinitionMap.get(beanName); // 查找是否存在同名的bean if (existingDefinition != null) { // 有同名的bean存在时 if (!isAllowBeanDefinitionOverriding()) { throw new BeanDefinitionOverrideException(beanName, beanDefinition, existingDefinition); } else if (existingDefinition.getRole() < beanDefinition.getRole()) { // e.g. was ROLE_APPLICATION, now overriding with ROLE_SUPPORT or ROLE_INFRASTRUCTURE if (logger.isInfoEnabled()) { logger.info("Overriding user-defined bean definition for bean '" + beanName + "' with a framework-generated bean definition: replacing [" + existingDefinition + "] with [" + beanDefinition + "]"); } } else if (!beanDefinition.equals(existingDefinition)) { if (logger.isDebugEnabled()) { logger.debug("Overriding bean definition for bean '" + beanName + "' with a different definition: replacing [" + existingDefinition + "] with [" + beanDefinition + "]"); } } else { if (logger.isTraceEnabled()) { logger.trace("Overriding bean definition for bean '" + beanName + "' with an equivalent definition: replacing [" + existingDefinition + "] with [" + beanDefinition + "]"); } } this.beanDefinitionMap.put(beanName, beanDefinition); } else { // 没有同名的bean存在时 if (hasBeanCreationStarted()) { // Cannot modify startup-time collection elements anymore (for stable iteration) synchronized (this.beanDefinitionMap) { // beanDefinitionMap存储beanName:BeanDefinition一一对应的K:V信息 // beanName作为key， beanDefinition作为value存入DefaultListableBeanFactory对象的beanDefinitionMap字段中 // 完成Bean的注册，将Bean注册到BeanFactory中 this.beanDefinitionMap.put(beanName, beanDefinition); List<String> updatedDefinitions = new ArrayList<>(this.beanDefinitionNames.size() + 1); updatedDefinitions.addAll(this.beanDefinitionNames); updatedDefinitions.add(beanName); // 将所有的beanName保存到beanDefinitionNames字段中，数据类型为 this.beanDefinitionNames = updatedDefinitions; removeManualSingletonName(beanName); } } else { // Still in startup registration phase this.beanDefinitionMap.put(beanName, beanDefinition); this.beanDefinitionNames.add(beanName); removeManualSingletonName(beanName); } this.frozenBeanDefinitionNames = null; } if (existingDefinition != null || containsSingleton(beanName)) { resetBeanDefinition(beanName); } } - 到此上面的 loadBeanDefinitions(XmlBeanDefinitionReader reader)方法基本执行完成
- 上一级的loadBeanDefinitions(DefaultListableBeanFactory beanFactory)方法也执行到loadBeanDefinitions(XmlBeanDefinitionReader reader)方法后结束
- 在上述创建BeanFactory的过程中，BeanDefination注册到BeanFactory（DefaultListableBeanFactory）中的类型为ConcurrentHashMap
- 向beanDefinitionMap中注册时beanName为key,beanDefination为value；
- DefaultListableBeanFactory对象的字段beanDefinitionNames是一个ArrayList
类型数据，用于存储所有已经注册的Bean的名称 - refreshBeanFactory()方法执行完成，接下来进入其下一行的getBeanFactory()方法
getBeanFactory()方法的一种实现¶
- AbstractRefreshableApplicationContext中getBeanFactory()方法的一种实现
- 获取BeanFactory
Java
@Override public final ConfigurableListableBeanFactory getBeanFactory() { synchronized (this.beanFactoryMonitor) { if (this.beanFactory == null) { throw new IllegalStateException("BeanFactory not initialized or already closed - call 'refresh' before accessing beans via the ApplicationContext"); } return this.beanFactory; } } - getBeanFactory()方法执行完，标志上一级的方法obtainFreshBeanFactory()执行完成，接下来将进入AbstractApplicationContext抽象类中定义的refresh()模板方法中的第三步定义的prepareBeanFactory(beanFactory)方法
6 prepareBeanFactory(beanFactory)方法¶
- 代码位置: org.springframework.context.support.AbstractApplicationContext.java
Java
protected void prepareBeanFactory(ConfigurableListableBeanFactory beanFactory) { // Tell the internal bean factory to use the context's class loader etc. beanFactory.setBeanClassLoader(getClassLoader()); beanFactory.setBeanExpressionResolver(new StandardBeanExpressionResolver(beanFactory.getBeanClassLoader())); beanFactory.addPropertyEditorRegistrar(new ResourceEditorRegistrar(this, getEnvironment())); // Configure the bean factory with context callbacks. beanFactory.addBeanPostProcessor(new ApplicationContextAwareProcessor(this)); beanFactory.ignoreDependencyInterface(EnvironmentAware.class); beanFactory.ignoreDependencyInterface(EmbeddedValueResolverAware.class); beanFactory.ignoreDependencyInterface(ResourceLoaderAware.class); beanFactory.ignoreDependencyInterface(ApplicationEventPublisherAware.class); beanFactory.ignoreDependencyInterface(MessageSourceAware.class); beanFactory.ignoreDependencyInterface(ApplicationContextAware.class); // BeanFactory interface not registered as resolvable type in a plain factory. // MessageSource registered (and found for autowiring) as a bean. beanFactory.registerResolvableDependency(BeanFactory.class, beanFactory); beanFactory.registerResolvableDependency(ResourceLoader.class, this); beanFactory.registerResolvableDependency(ApplicationEventPublisher.class, this); beanFactory.registerResolvableDependency(ApplicationContext.class, this); // Register early post-processor for detecting inner beans as ApplicationListeners. beanFactory.addBeanPostProcessor(new ApplicationListenerDetector(this)); // Detect a LoadTimeWeaver and prepare for weaving, if found. if (beanFactory.containsBean(LOAD_TIME_WEAVER_BEAN_NAME)) { beanFactory.addBeanPostProcessor(new LoadTimeWeaverAwareProcessor(beanFactory)); // Set a temporary ClassLoader for type matching. beanFactory.setTempClassLoader(new ContextTypeMatchClassLoader(beanFactory.getBeanClassLoader())); } // Register default environment beans. if (!beanFactory.containsLocalBean(ENVIRONMENT_BEAN_NAME)) { beanFactory.registerSingleton(ENVIRONMENT_BEAN_NAME, getEnvironment()); } if (!beanFactory.containsLocalBean(SYSTEM_PROPERTIES_BEAN_NAME)) { beanFactory.registerSingleton(SYSTEM_PROPERTIES_BEAN_NAME, getEnvironment().getSystemProperties()); } if (!beanFactory.containsLocalBean(SYSTEM_ENVIRONMENT_BEAN_NAME)) { beanFactory.registerSingleton(SYSTEM_ENVIRONMENT_BEAN_NAME, getEnvironment().getSystemEnvironment()); } }
7 postProcessBeanFactory(ConfigurableListableBeanFactory beanFactory)¶
- 代码位置:org.springframework.context.support.AbstractApplicationContext.java
- postProcessBeanFactory(beanFactory)执行完后进入 invokeBeanFactoryPostProcessors(beanFactory)方法
8. invokeBeanFactoryPostProcessors(beanFactory)方法¶
Java
protected void invokeBeanFactoryPostProcessors(ConfigurableListableBeanFactory beanFactory) {
PostProcessorRegistrationDelegate.invokeBeanFactoryPostProcessors(beanFactory, getBeanFactoryPostProcessors());
// Detect a LoadTimeWeaver and prepare for weaving, if found in the meantime
// (e.g. through an @Bean method registered by ConfigurationClassPostProcessor)
if (beanFactory.getTempClassLoader() == null && beanFactory.containsBean(LOAD_TIME_WEAVER_BEAN_NAME)) {
beanFactory.addBeanPostProcessor(new LoadTimeWeaverAwareProcessor(beanFactory));
beanFactory.setTempClassLoader(new ContextTypeMatchClassLoader(beanFactory.getBeanClassLoader()));
}
}
public List<BeanFactoryPostProcessor> getBeanFactoryPostProcessors() {
return this.beanFactoryPostProcessors;
}
- PostProcessorRegistrationDelegate的invokeBeanFactoryPostProcessors(ConfigurableListableBeanFactory beanFactory, List
beanFactoryPostProcessors)静态方法 Javapublic static void invokeBeanFactoryPostProcessors( ConfigurableListableBeanFactory beanFactory, List<BeanFactoryPostProcessor> beanFactoryPostProcessors) { // Invoke BeanDefinitionRegistryPostProcessors first, if any. Set<String> processedBeans = new HashSet<>(); if (beanFactory instanceof BeanDefinitionRegistry) { BeanDefinitionRegistry registry = (BeanDefinitionRegistry) beanFactory; List<BeanFactoryPostProcessor> regularPostProcessors = new ArrayList<>(); List<BeanDefinitionRegistryPostProcessor> registryProcessors = new ArrayList<>(); for (BeanFactoryPostProcessor postProcessor : beanFactoryPostProcessors) { if (postProcessor instanceof BeanDefinitionRegistryPostProcessor) { BeanDefinitionRegistryPostProcessor registryProcessor = (BeanDefinitionRegistryPostProcessor) postProcessor; registryProcessor.postProcessBeanDefinitionRegistry(registry); registryProcessors.add(registryProcessor); } else { regularPostProcessors.add(postProcessor); } } // Do not initialize FactoryBeans here: We need to leave all regular beans // uninitialized to let the bean factory post-processors apply to them! // Separate between BeanDefinitionRegistryPostProcessors that implement // PriorityOrdered, Ordered, and the rest. List<BeanDefinitionRegistryPostProcessor> currentRegistryProcessors = new ArrayList<>(); // First, invoke the BeanDefinitionRegistryPostProcessors that implement PriorityOrdered. String[] postProcessorNames = beanFactory.getBeanNamesForType(BeanDefinitionRegistryPostProcessor.class, true, false); for (String ppName : postProcessorNames) { if (beanFactory.isTypeMatch(ppName, PriorityOrdered.class)) { currentRegistryProcessors.add(beanFactory.getBean(ppName, BeanDefinitionRegistryPostProcessor.class)); processedBeans.add(ppName); } } sortPostProcessors(currentRegistryProcessors, beanFactory); registryProcessors.addAll(currentRegistryProcessors); invokeBeanDefinitionRegistryPostProcessors(currentRegistryProcessors, registry); currentRegistryProcessors.clear(); // Next, invoke the BeanDefinitionRegistryPostProcessors that implement Ordered. postProcessorNames = beanFactory.getBeanNamesForType(BeanDefinitionRegistryPostProcessor.class, true, false); for (String ppName : postProcessorNames) { if (!processedBeans.contains(ppName) && beanFactory.isTypeMatch(ppName, Ordered.class)) { currentRegistryProcessors.add(beanFactory.getBean(ppName, BeanDefinitionRegistryPostProcessor.class)); processedBeans.add(ppName); } } sortPostProcessors(currentRegistryProcessors, beanFactory); registryProcessors.addAll(currentRegistryProcessors); invokeBeanDefinitionRegistryPostProcessors(currentRegistryProcessors, registry); currentRegistryProcessors.clear(); // Finally, invoke all other BeanDefinitionRegistryPostProcessors until no further ones appear. boolean reiterate = true; while (reiterate) { reiterate = false; postProcessorNames = beanFactory.getBeanNamesForType(BeanDefinitionRegistryPostProcessor.class, true, false); for (String ppName : postProcessorNames) { if (!processedBeans.contains(ppName)) { currentRegistryProcessors.add(beanFactory.getBean(ppName, BeanDefinitionRegistryPostProcessor.class)); processedBeans.add(ppName); reiterate = true; } } sortPostProcessors(currentRegistryProcessors, beanFactory); registryProcessors.addAll(currentRegistryProcessors); invokeBeanDefinitionRegistryPostProcessors(currentRegistryProcessors, registry); currentRegistryProcessors.clear(); } // Now, invoke the postProcessBeanFactory callback of all processors handled so far. invokeBeanFactoryPostProcessors(registryProcessors, beanFactory); invokeBeanFactoryPostProcessors(regularPostProcessors, beanFactory); } else { // Invoke factory processors registered with the context instance. invokeBeanFactoryPostProcessors(beanFactoryPostProcessors, beanFactory); } // Do not initialize FactoryBeans here: We need to leave all regular beans // uninitialized to let the bean factory post-processors apply to them! String[] postProcessorNames = beanFactory.getBeanNamesForType(BeanFactoryPostProcessor.class, true, false); // Separate between BeanFactoryPostProcessors that implement PriorityOrdered, // Ordered, and the rest. List<BeanFactoryPostProcessor> priorityOrderedPostProcessors = new ArrayList<>(); List<String> orderedPostProcessorNames = new ArrayList<>(); List<String> nonOrderedPostProcessorNames = new ArrayList<>(); for (String ppName : postProcessorNames) { if (processedBeans.contains(ppName)) { // skip - already processed in first phase above } else if (beanFactory.isTypeMatch(ppName, PriorityOrdered.class)) { priorityOrderedPostProcessors.add(beanFactory.getBean(ppName, BeanFactoryPostProcessor.class)); } else if (beanFactory.isTypeMatch(ppName, Ordered.class)) { orderedPostProcessorNames.add(ppName); } else { nonOrderedPostProcessorNames.add(ppName); } } // First, invoke the BeanFactoryPostProcessors that implement PriorityOrdered. sortPostProcessors(priorityOrderedPostProcessors, beanFactory); invokeBeanFactoryPostProcessors(priorityOrderedPostProcessors, beanFactory); // Next, invoke the BeanFactoryPostProcessors that implement Ordered. List<BeanFactoryPostProcessor> orderedPostProcessors = new ArrayList<>(orderedPostProcessorNames.size()); for (String postProcessorName : orderedPostProcessorNames) { orderedPostProcessors.add(beanFactory.getBean(postProcessorName, BeanFactoryPostProcessor.class)); } sortPostProcessors(orderedPostProcessors, beanFactory); invokeBeanFactoryPostProcessors(orderedPostProcessors, beanFactory); // Finally, invoke all other BeanFactoryPostProcessors. List<BeanFactoryPostProcessor> nonOrderedPostProcessors = new ArrayList<>(nonOrderedPostProcessorNames.size()); for (String postProcessorName : nonOrderedPostProcessorNames) { nonOrderedPostProcessors.add(beanFactory.getBean(postProcessorName, BeanFactoryPostProcessor.class)); } invokeBeanFactoryPostProcessors(nonOrderedPostProcessors, beanFactory); // Clear cached merged bean definitions since the post-processors might have // modified the original metadata, e.g. replacing placeholders in values... beanFactory.clearMetadataCache(); } // 上面的方法内部有调用该重载方法 private static void invokeBeanDefinitionRegistryPostProcessors( Collection<? extends BeanDefinitionRegistryPostProcessor> postProcessors, BeanDefinitionRegistry registry) { for (BeanDefinitionRegistryPostProcessor postProcessor : postProcessors) { postProcessor.postProcessBeanDefinitionRegistry(registry); } } // 上面的方法内部有调用该方法 private static void sortPostProcessors(List<?> postProcessors, ConfigurableListableBeanFactory beanFactory) { Comparator<Object> comparatorToUse = null; if (beanFactory instanceof DefaultListableBeanFactory) { comparatorToUse = ((DefaultListableBeanFactory) beanFactory).getDependencyComparator(); } if (comparatorToUse == null) { comparatorToUse = OrderComparator.INSTANCE; } postProcessors.sort(comparatorToUse); }
9. registerBeanPostProcessors(beanFactory);方法¶
Java
- PostProcessorRegistrationDelegate的registerBeanPostProcessors(ConfigurableListableBeanFactory beanFactory, AbstractApplicationContext applicationContexs)静态方法，具体代码如下：
protected void registerBeanPostProcessors(ConfigurableListableBeanFactory beanFactory) {
PostProcessorRegistrationDelegate.registerBeanPostProcessors(beanFactory, this);
}
Java
public static void registerBeanPostProcessors(
ConfigurableListableBeanFactory beanFactory, AbstractApplicationContext applicationContext) {
String[] postProcessorNames = beanFactory.getBeanNamesForType(BeanPostProcessor.class, true, false);
// Register BeanPostProcessorChecker that logs an info message when
// a bean is created during BeanPostProcessor instantiation, i.e. when
// a bean is not eligible for getting processed by all BeanPostProcessors.
int beanProcessorTargetCount = beanFactory.getBeanPostProcessorCount() + 1 + postProcessorNames.length;
beanFactory.addBeanPostProcessor(new BeanPostProcessorChecker(beanFactory, beanProcessorTargetCount));
// Separate between BeanPostProcessors that implement PriorityOrdered,
// Ordered, and the rest.
List<BeanPostProcessor> priorityOrderedPostProcessors = new ArrayList<>();
List<BeanPostProcessor> internalPostProcessors = new ArrayList<>();
List<String> orderedPostProcessorNames = new ArrayList<>();
List<String> nonOrderedPostProcessorNames = new ArrayList<>();
for (String ppName : postProcessorNames) {
if (beanFactory.isTypeMatch(ppName, PriorityOrdered.class)) {
BeanPostProcessor pp = beanFactory.getBean(ppName, BeanPostProcessor.class);
priorityOrderedPostProcessors.add(pp);
if (pp instanceof MergedBeanDefinitionPostProcessor) {
internalPostProcessors.add(pp);
}
}
else if (beanFactory.isTypeMatch(ppName, Ordered.class)) {
orderedPostProcessorNames.add(ppName);
}
else {
nonOrderedPostProcessorNames.add(ppName);
}
}
// First, register the BeanPostProcessors that implement PriorityOrdered.
sortPostProcessors(priorityOrderedPostProcessors, beanFactory);
registerBeanPostProcessors(beanFactory, priorityOrderedPostProcessors);
// Next, register the BeanPostProcessors that implement Ordered.
List<BeanPostProcessor> orderedPostProcessors = new ArrayList<>(orderedPostProcessorNames.size());
for (String ppName : orderedPostProcessorNames) {
BeanPostProcessor pp = beanFactory.getBean(ppName, BeanPostProcessor.class);
orderedPostProcessors.add(pp);
if (pp instanceof MergedBeanDefinitionPostProcessor) {
internalPostProcessors.add(pp);
}
}
sortPostProcessors(orderedPostProcessors, beanFactory);
registerBeanPostProcessors(beanFactory, orderedPostProcessors);
// Now, register all regular BeanPostProcessors.
List<BeanPostProcessor> nonOrderedPostProcessors = new ArrayList<>(nonOrderedPostProcessorNames.size());
for (String ppName : nonOrderedPostProcessorNames) {
BeanPostProcessor pp = beanFactory.getBean(ppName, BeanPostProcessor.class);
nonOrderedPostProcessors.add(pp);
if (pp instanceof MergedBeanDefinitionPostProcessor) {
internalPostProcessors.add(pp);
}
}
registerBeanPostProcessors(beanFactory, nonOrderedPostProcessors);
// Finally, re-register all internal BeanPostProcessors.
sortPostProcessors(internalPostProcessors, beanFactory);
registerBeanPostProcessors(beanFactory, internalPostProcessors);
// Re-register post-processor for detecting inner beans as ApplicationListeners,
// moving it to the end of the processor chain (for picking up proxies etc).
beanFactory.addBeanPostProcessor(new ApplicationListenerDetector(applicationContext));
}
//上面的方法内部有调用该重载方法
private static void registerBeanPostProcessors(
ConfigurableListableBeanFactory beanFactory, List<BeanPostProcessor> postProcessors) {
for (BeanPostProcessor postProcessor : postProcessors) {
beanFactory.addBeanPostProcessor(postProcessor);
}
}
10. initMessageSource();方法¶
- org.springframework.context.support.AbstractApplicationContext中的initMessageSource()方法
Java
protected void initMessageSource() { ConfigurableListableBeanFactory beanFactory = getBeanFactory(); if (beanFactory.containsLocalBean(MESSAGE_SOURCE_BEAN_NAME)) { this.messageSource = beanFactory.getBean(MESSAGE_SOURCE_BEAN_NAME, MessageSource.class); // Make MessageSource aware of parent MessageSource. if (this.parent != null && this.messageSource instanceof HierarchicalMessageSource) { HierarchicalMessageSource hms = (HierarchicalMessageSource) this.messageSource; if (hms.getParentMessageSource() == null) { // Only set parent context as parent MessageSource if no parent MessageSource // registered already. hms.setParentMessageSource(getInternalParentMessageSource()); } } if (logger.isTraceEnabled()) { logger.trace("Using MessageSource [" + this.messageSource + "]"); } } else { // Use empty MessageSource to be able to accept getMessage calls. DelegatingMessageSource dms = new DelegatingMessageSource(); dms.setParentMessageSource(getInternalParentMessageSource()); this.messageSource = dms; beanFactory.registerSingleton(MESSAGE_SOURCE_BEAN_NAME, this.messageSource); if (logger.isTraceEnabled()) { logger.trace("No '" + MESSAGE_SOURCE_BEAN_NAME + "' bean, using [" + this.messageSource + "]"); } } }
11. initApplicationEventMulticaster();方法¶
- org.springframework.context.support.AbstractApplicationContext中的initApplicationEventMulticaster()方法
Java
protected void initApplicationEventMulticaster() { ConfigurableListableBeanFactory beanFactory = getBeanFactory(); if (beanFactory.containsLocalBean(APPLICATION_EVENT_MULTICASTER_BEAN_NAME)) { this.applicationEventMulticaster = beanFactory.getBean(APPLICATION_EVENT_MULTICASTER_BEAN_NAME, ApplicationEventMulticaster.class); if (logger.isTraceEnabled()) { logger.trace("Using ApplicationEventMulticaster [" + this.applicationEventMulticaster + "]"); } } else { this.applicationEventMulticaster = new SimpleApplicationEventMulticaster(beanFactory); beanFactory.registerSingleton(APPLICATION_EVENT_MULTICASTER_BEAN_NAME, this.applicationEventMulticaster); if (logger.isTraceEnabled()) { logger.trace("No '" + APPLICATION_EVENT_MULTICASTER_BEAN_NAME + "' bean, using " + "[" + this.applicationEventMulticaster.getClass().getSimpleName() + "]"); } } }
12. onRefresh();方法¶
- org.springframework.context.support.AbstractApplicationContext中的onRefresh()方法
13. registerListeners();方法¶
- org.springframework.context.support.AbstractApplicationContext中的registerListeners()方法
Java
protected void registerListeners() { // Register statically specified listeners first. for (ApplicationListener<?> listener : getApplicationListeners()) { getApplicationEventMulticaster().addApplicationListener(listener); } // Do not initialize FactoryBeans here: We need to leave all regular beans // uninitialized to let post-processors apply to them! String[] listenerBeanNames = getBeanNamesForType(ApplicationListener.class, true, false); for (String listenerBeanName : listenerBeanNames) { getApplicationEventMulticaster().addApplicationListenerBean(listenerBeanName); } // Publish early application events now that we finally have a multicaster... Set<ApplicationEvent> earlyEventsToProcess = this.earlyApplicationEvents; this.earlyApplicationEvents = null; if (earlyEventsToProcess != null) { for (ApplicationEvent earlyEvent : earlyEventsToProcess) { getApplicationEventMulticaster().multicastEvent(earlyEvent); } } }
14. finishBeanFactoryInitialization(beanFactory);方法¶
- org.springframework.context.support.AbstractApplicationContext中的finishBeanFactoryInitialization(beanFactory)方法
- 实例化Bean的核心方法
Java
protected void finishBeanFactoryInitialization(ConfigurableListableBeanFactory beanFactory) { // Initialize conversion service for this context. if (beanFactory.containsBean(CONVERSION_SERVICE_BEAN_NAME) && beanFactory.isTypeMatch(CONVERSION_SERVICE_BEAN_NAME, ConversionService.class)) { beanFactory.setConversionService( beanFactory.getBean(CONVERSION_SERVICE_BEAN_NAME, ConversionService.class)); } // Register a default embedded value resolver if no bean post-processor // (such as a PropertyPlaceholderConfigurer bean) registered any before: // at this point, primarily for resolution in annotation attribute values. if (!beanFactory.hasEmbeddedValueResolver()) { beanFactory.addEmbeddedValueResolver(strVal -> getEnvironment().resolvePlaceholders(strVal)); } // Initialize LoadTimeWeaverAware beans early to allow for registering their transformers early. String[] weaverAwareNames = beanFactory.getBeanNamesForType(LoadTimeWeaverAware.class, false, false); for (String weaverAwareName : weaverAwareNames) { getBean(weaverAwareName); } // Stop using the temporary ClassLoader for type matching. beanFactory.setTempClassLoader(null); // Allow for caching all bean definition metadata, not expecting further changes. beanFactory.freezeConfiguration(); // Instantiate all remaining (non-lazy-init) singletons. // 实例化bean的核心代码 beanFactory.preInstantiateSingletons(); // 上一行的preInstantiateSingletons()方法定义在ConfigurableListableBeanFactory接口中， // 具体实现是在DefaultListableBeanFactory中preInstantiateSingletons()方法 }
DefaultListableBeanFactory中preInstantiateSingletons()方法¶
Java
@Override
public void preInstantiateSingletons() throws BeansException {
if (logger.isTraceEnabled()) {
logger.trace("Pre-instantiating singletons in " + this);
}
// Iterate over a copy to allow for init methods which in turn register new bean definitions.
// While this may not be part of the regular factory bootstrap, it does otherwise work fine.
List<String> beanNames = new ArrayList<>(this.beanDefinitionNames);
// Trigger initialization of all non-lazy singleton beans...
// 遍历beanDefinitionNames这个ArrayList对象中的beanName，
for (String beanName : beanNames) {
RootBeanDefinition bd = getMergedLocalBeanDefinition(beanName);
if (!bd.isAbstract() && bd.isSingleton() && !bd.isLazyInit()) {
if (isFactoryBean(beanName)) {
Object bean = getBean(FACTORY_BEAN_PREFIX + beanName);
if (bean instanceof FactoryBean) {
final FactoryBean<?> factory = (FactoryBean<?>) bean;
boolean isEagerInit;
if (System.getSecurityManager() != null && factory instanceof SmartFactoryBean) {
isEagerInit = AccessController.doPrivileged((PrivilegedAction<Boolean>)
((SmartFactoryBean<?>) factory)::isEagerInit,
getAccessControlContext());
}
else {
isEagerInit = (factory instanceof SmartFactoryBean &&
((SmartFactoryBean<?>) factory).isEagerInit());
}
if (isEagerInit) {
// 创建bean并递归构建Bean之间的依赖关系
getBean(beanName);
}
}
}
else {
// 创建bean并递归构建Bean之间的依赖关系
getBean(beanName);
}
}
}
// Trigger post-initialization callback for all applicable beans...
for (String beanName : beanNames) {
Object singletonInstance = getSingleton(beanName);
if (singletonInstance instanceof SmartInitializingSingleton) {
final SmartInitializingSingleton smartSingleton = (SmartInitializingSingleton) singletonInstance;
if (System.getSecurityManager() != null) {
AccessController.doPrivileged((PrivilegedAction<Object>) () -> {
smartSingleton.afterSingletonsInstantiated();
return null;
}, getAccessControlContext());
}
else {
smartSingleton.afterSingletonsInstantiated();
}
}
}
}
preInstantiateSingletons()方法中调用的getBean方法¶
- getBean方法定义在BeanFactory接口中
- getBean方法org.springframework.beans.factory.support.AbstractBeanFactory中实现
Java
@Override public Object getBean(String name) throws BeansException { return doGetBean(name, null, null, false); } //下面是上面方法调用doGetBean(name, null, null, false)方法 // 这个方法特别长，以下是完整代码： @SuppressWarnings("unchecked") protected <T> T doGetBean(final String name, @Nullable final Class<T> requiredType, @Nullable final Object[] args, boolean typeCheckOnly) throws BeansException { final String beanName = transformedBeanName(name); Object bean; // Eagerly check singleton cache for manually registered singletons. Object sharedInstance = getSingleton(beanName); if (sharedInstance != null && args == null) { if (logger.isTraceEnabled()) { if (isSingletonCurrentlyInCreation(beanName)) { logger.trace("Returning eagerly cached instance of singleton bean '" + beanName + "' that is not fully initialized yet - a consequence of a circular reference"); } else { logger.trace("Returning cached instance of singleton bean '" + beanName + "'"); } } bean = getObjectForBeanInstance(sharedInstance, name, beanName, null); } else { // Fail if we're already creating this bean instance: // We're assumably within a circular reference. if (isPrototypeCurrentlyInCreation(beanName)) { throw new BeanCurrentlyInCreationException(beanName); } // Check if bean definition exists in this factory. BeanFactory parentBeanFactory = getParentBeanFactory(); if (parentBeanFactory != null && !containsBeanDefinition(beanName)) { // Not found -> check parent. String nameToLookup = originalBeanName(name); if (parentBeanFactory instanceof AbstractBeanFactory) { return ((AbstractBeanFactory) parentBeanFactory).doGetBean( nameToLookup, requiredType, args, typeCheckOnly); } else if (args != null) { // Delegation to parent with explicit args. return (T) parentBeanFactory.getBean(nameToLookup, args); } else if (requiredType != null) { // No args -> delegate to standard getBean method. return parentBeanFactory.getBean(nameToLookup, requiredType); } else { return (T) parentBeanFactory.getBean(nameToLookup); } } if (!typeCheckOnly) { markBeanAsCreated(beanName); } try { final RootBeanDefinition mbd = getMergedLocalBeanDefinition(beanName); checkMergedBeanDefinition(mbd, beanName, args); // Guarantee initialization of beans that the current bean depends on. // 获取当前bean的依赖关系 String[] dependsOn = mbd.getDependsOn(); // 根据依赖的beanName递归调用getBean()方法，不断探寻其依赖的bean，直到getSingleton方法返回依赖的Bean，即当前正在创建的Bean // 直到依赖关系最底层的bean没有依赖对象了，至此整个递归过程结束 if (dependsOn != null) { for (String dep : dependsOn) { if (isDependent(beanName, dep)) { throw new BeanCreationException(mbd.getResourceDescription(), beanName, "Circular depends-on relationship between '" + beanName + "' and '" + dep + "'"); } // registerDependentBean(dep, beanName); try { getBean(dep); } catch (NoSuchBeanDefinitionException ex) { throw new BeanCreationException(mbd.getResourceDescription(), beanName, "'" + beanName + "' depends on missing bean '" + dep + "'", ex); } } } // Create bean instance. if (mbd.isSingleton()) { // getSingleton方法的参数是createBean(beanName, mbd, args)方法的返回值 sharedInstance = getSingleton(beanName, () -> { try { // createBean方法在AbstractBeanFactory抽象类中定义，具体实现是在AbstractAutowireCapableBeanFactory抽象类中 return createBean(beanName, mbd, args); } catch (BeansException ex) { // Explicitly remove instance from singleton cache: It might have been put there // eagerly by the creation process, to allow for circular reference resolution. // Also remove any beans that received a temporary reference to the bean. destroySingleton(beanName); throw ex; } }); bean = getObjectForBeanInstance(sharedInstance, name, beanName, mbd); } else if (mbd.isPrototype()) { // It's a prototype -> create a new instance. Object prototypeInstance = null; try { beforePrototypeCreation(beanName); prototypeInstance = createBean(beanName, mbd, args); } finally { afterPrototypeCreation(beanName); } bean = getObjectForBeanInstance(prototypeInstance, name, beanName, mbd); } else { String scopeName = mbd.getScope(); final Scope scope = this.scopes.get(scopeName); if (scope == null) { throw new IllegalStateException("No Scope registered for scope name '" + scopeName + "'"); } try { Object scopedInstance = scope.get(beanName, () -> { beforePrototypeCreation(beanName); try { return createBean(beanName, mbd, args); } finally { afterPrototypeCreation(beanName); } }); bean = getObjectForBeanInstance(scopedInstance, name, beanName, mbd); } catch (IllegalStateException ex) { throw new BeanCreationException(beanName, "Scope '" + scopeName + "' is not active for the current thread; consider " + "defining a scoped proxy for this bean if you intend to refer to it from a singleton", ex); } } } catch (BeansException ex) { cleanupAfterBeanCreationFailure(beanName); throw ex; } } // Check if required type matches the type of the actual bean instance. if (requiredType != null && !requiredType.isInstance(bean)) { try { T convertedBean = getTypeConverter().convertIfNecessary(bean, requiredType); if (convertedBean == null) { throw new BeanNotOfRequiredTypeException(name, requiredType, bean.getClass()); } return convertedBean; } catch (TypeMismatchException ex) { if (logger.isTraceEnabled()) { logger.trace("Failed to convert bean '" + name + "' to required type '" + ClassUtils.getQualifiedName(requiredType) + "'", ex); } throw new BeanNotOfRequiredTypeException(name, requiredType, bean.getClass()); } } return (T) bean; }
AbstractAutowireCapableBeanFactory类中的createBean(String beanName, RootBeanDefinition mbd, @Nullable Object[] args)方法¶
- 代码位置：org.springframework.beans.factory.support.AbstractAutowireCapableBeanFactory
Java
@Override protected Object createBean(String beanName, RootBeanDefinition mbd, @Nullable Object[] args) throws BeanCreationException { if (logger.isTraceEnabled()) { logger.trace("Creating instance of bean '" + beanName + "'"); } RootBeanDefinition mbdToUse = mbd; // Make sure bean class is actually resolved at this point, and // clone the bean definition in case of a dynamically resolved Class // which cannot be stored in the shared merged bean definition. Class<?> resolvedClass = resolveBeanClass(mbd, beanName); if (resolvedClass != null && !mbd.hasBeanClass() && mbd.getBeanClassName() != null) { mbdToUse = new RootBeanDefinition(mbd); mbdToUse.setBeanClass(resolvedClass); } // Prepare method overrides. try { mbdToUse.prepareMethodOverrides(); } catch (BeanDefinitionValidationException ex) { throw new BeanDefinitionStoreException(mbdToUse.getResourceDescription(), beanName, "Validation of method overrides failed", ex); } try { // Give BeanPostProcessors a chance to return a proxy instead of the target bean instance. Object bean = resolveBeforeInstantiation(beanName, mbdToUse); if (bean != null) { return bean; } } catch (Throwable ex) { throw new BeanCreationException(mbdToUse.getResourceDescription(), beanName, "BeanPostProcessor before instantiation of bean failed", ex); } try { // createBean方法的核心 该方法会返回Bean对象的实例，具体代码在下面贴出 Object beanInstance = doCreateBean(beanName, mbdToUse, args); if (logger.isTraceEnabled()) { logger.trace("Finished creating instance of bean '" + beanName + "'"); } return beanInstance; } catch (BeanCreationException | ImplicitlyAppearedSingletonException ex) { // A previously detected exception with proper bean creation context already, // or illegal singleton state to be communicated up to DefaultSingletonBeanRegistry. throw ex; } catch (Throwable ex) { throw new BeanCreationException( mbdToUse.getResourceDescription(), beanName, "Unexpected exception during bean creation", ex); } } // 在AbstractAutowireCapableBeanFactory抽象类的createBean方法中调用的doCreateBean(beanName, mbdToUse, args)方法 protected Object doCreateBean(final String beanName, final RootBeanDefinition mbd, final @Nullable Object[] args) throws BeanCreationException { // Instantiate the bean. BeanWrapper instanceWrapper = null; if (mbd.isSingleton()) { instanceWrapper = this.factoryBeanInstanceCache.remove(beanName); } if (instanceWrapper == null) { // 创建Bean实例 instanceWrapper = createBeanInstance(beanName, mbd, args); } final Object bean = instanceWrapper.getWrappedInstance(); Class<?> beanType = instanceWrapper.getWrappedClass(); if (beanType != NullBean.class) { mbd.resolvedTargetType = beanType; } // Allow post-processors to modify the merged bean definition. synchronized (mbd.postProcessingLock) { if (!mbd.postProcessed) { try { applyMergedBeanDefinitionPostProcessors(mbd, beanType, beanName); } catch (Throwable ex) { throw new BeanCreationException(mbd.getResourceDescription(), beanName, "Post-processing of merged bean definition failed", ex); } mbd.postProcessed = true; } } // Eagerly cache singletons to be able to resolve circular references // even when triggered by lifecycle interfaces like BeanFactoryAware. boolean earlySingletonExposure = (mbd.isSingleton() && this.allowCircularReferences && isSingletonCurrentlyInCreation(beanName)); if (earlySingletonExposure) { if (logger.isTraceEnabled()) { logger.trace("Eagerly caching bean '" + beanName + "' to allow for resolving potential circular references"); } addSingletonFactory(beanName, () -> getEarlyBeanReference(beanName, mbd, bean)); } // Initialize the bean instance. Object exposedObject = bean; try { // 填充bean，实际进行依赖注入的地方 populateBean(beanName, mbd, instanceWrapper); exposedObject = initializeBean(beanName, exposedObject, mbd); } catch (Throwable ex) { if (ex instanceof BeanCreationException && beanName.equals(((BeanCreationException) ex).getBeanName())) { throw (BeanCreationException) ex; } else { throw new BeanCreationException( mbd.getResourceDescription(), beanName, "Initialization of bean failed", ex); } } if (earlySingletonExposure) { Object earlySingletonReference = getSingleton(beanName, false); if (earlySingletonReference != null) { if (exposedObject == bean) { exposedObject = earlySingletonReference; } else if (!this.allowRawInjectionDespiteWrapping && hasDependentBean(beanName)) { String[] dependentBeans = getDependentBeans(beanName); Set<String> actualDependentBeans = new LinkedHashSet<>(dependentBeans.length); for (String dependentBean : dependentBeans) { if (!removeSingletonIfCreatedForTypeCheckOnly(dependentBean)) { actualDependentBeans.add(dependentBean); } } if (!actualDependentBeans.isEmpty()) { throw new BeanCurrentlyInCreationException(beanName, "Bean with name '" + beanName + "' has been injected into other beans [" + StringUtils.collectionToCommaDelimitedString(actualDependentBeans) + "] in its raw version as part of a circular reference, but has eventually been " + "wrapped. This means that said other beans do not use the final version of the " + "bean. This is often the result of over-eager type matching - consider using " + "'getBeanNamesOfType' with the 'allowEagerInit' flag turned off, for example."); } } } } // Register bean as disposable. try { registerDisposableBeanIfNecessary(beanName, bean, mbd); } catch (BeanDefinitionValidationException ex) { throw new BeanCreationException( mbd.getResourceDescription(), beanName, "Invalid destruction signature", ex); } return exposedObject; } // 在AbstractAutowireCapableBeanFactory抽象类的doCreateBean方法中调用的 createBeanInstance(beanName, mbd, args)方法 protected BeanWrapper createBeanInstance(String beanName, RootBeanDefinition mbd, @Nullable Object[] args) { // Make sure bean class is actually resolved at this point. Class<?> beanClass = resolveBeanClass(mbd, beanName); if (beanClass != null && !Modifier.isPublic(beanClass.getModifiers()) && !mbd.isNonPublicAccessAllowed()) { throw new BeanCreationException(mbd.getResourceDescription(), beanName, "Bean class isn't public, and non-public access not allowed: " + beanClass.getName()); } Supplier<?> instanceSupplier = mbd.getInstanceSupplier(); if (instanceSupplier != null) { return obtainFromSupplier(instanceSupplier, beanName); } if (mbd.getFactoryMethodName() != null) { return instantiateUsingFactoryMethod(beanName, mbd, args); } // Shortcut when re-creating the same bean... boolean resolved = false; boolean autowireNecessary = false; if (args == null) { synchronized (mbd.constructorArgumentLock) { if (mbd.resolvedConstructorOrFactoryMethod != null) { resolved = true; autowireNecessary = mbd.constructorArgumentsResolved; } } } if (resolved) { if (autowireNecessary) { return autowireConstructor(beanName, mbd, null, null); } else { // 调用instantiateBean方法 return instantiateBean(beanName, mbd); } } // Candidate constructors for autowiring? Constructor<?>[] ctors = determineConstructorsFromBeanPostProcessors(beanClass, beanName); if (ctors != null || mbd.getResolvedAutowireMode() == AUTOWIRE_CONSTRUCTOR || mbd.hasConstructorArgumentValues() || !ObjectUtils.isEmpty(args)) { return autowireConstructor(beanName, mbd, ctors, args); } // Preferred constructors for default construction? ctors = mbd.getPreferredConstructors(); if (ctors != null) { return autowireConstructor(beanName, mbd, ctors, null); } // No special handling: simply use no-arg constructor. return instantiateBean(beanName, mbd); } // 在AbstractAutowireCapableBeanFactory抽象类的createBeanInstance方法中调用的instantiateBean(beanName, mbd)方法 protected BeanWrapper instantiateBean(final String beanName, final RootBeanDefinition mbd) { try { Object beanInstance; final BeanFactory parent = this; if (System.getSecurityManager() != null) { // 核心逻辑 beanInstance = AccessController.doPrivileged((PrivilegedAction<Object>) () -> getInstantiationStrategy().instantiate(mbd, beanName, parent), getAccessControlContext()); } else { // 核心逻辑 beanInstance = getInstantiationStrategy().instantiate(mbd, beanName, parent); } BeanWrapper bw = new BeanWrapperImpl(beanInstance); initBeanWrapper(bw); return bw; } catch (Throwable ex) { throw new BeanCreationException( mbd.getResourceDescription(), beanName, "Instantiation of bean failed", ex); } } // 上面的getInstantiationStrategy()方法代码 protected InstantiationStrategy getInstantiationStrategy() { return this.instantiationStrategy; }
getInstantiationStrategy()方法的返回接口对象的策略对象的一个实现SimpleInstantiationStrategy¶
- org.springframework.beans.factory.support.SimpleInstantiationStrategy
- SimpleInstantiationStrategy.instantiate(RootBeanDefinition bd, @Nullable String beanName, BeanFactory owner)方法的具体实现：
Java
@Override public Object instantiate(RootBeanDefinition bd, @Nullable String beanName, BeanFactory owner) { // Don't override the class with CGLIB if no overrides. if (!bd.hasMethodOverrides()) { Constructor<?> constructorToUse; synchronized (bd.constructorArgumentLock) { constructorToUse = (Constructor<?>) bd.resolvedConstructorOrFactoryMethod; if (constructorToUse == null) { final Class<?> clazz = bd.getBeanClass(); if (clazz.isInterface()) { throw new BeanInstantiationException(clazz, "Specified class is an interface"); } try { if (System.getSecurityManager() != null) { constructorToUse = AccessController.doPrivileged( (PrivilegedExceptionAction<Constructor<?>>) clazz::getDeclaredConstructor); } else { constructorToUse = clazz.getDeclaredConstructor(); } bd.resolvedConstructorOrFactoryMethod = constructorToUse; } catch (Throwable ex) { throw new BeanInstantiationException(clazz, "No default constructor found", ex); } } } // 调用静态方法BeanUtils.instantiateClass(constructorToUse); return BeanUtils.instantiateClass(constructorToUse); } else { // Must generate CGLIB subclass. return instantiateWithMethodInjection(bd, beanName, owner); } }
静态方法BeanUtils.instantiateClass(constructorToUse)的实现细节¶
- 代码位置：org.springframework.beans.BeanUtils
Java
public static <T> T instantiateClass(Constructor<T> ctor, Object... args) throws BeanInstantiationException { Assert.notNull(ctor, "Constructor must not be null"); try { ReflectionUtils.makeAccessible(ctor); // 判断是否是Kotlin类型 if (KotlinDetector.isKotlinReflectPresent() && KotlinDetector.isKotlinType(ctor.getDeclaringClass())) { // 是Kotlin类型 return KotlinDelegate.instantiateClass(ctor, args); } else { // 不是Kotlin类型 Class<?>[] parameterTypes = ctor.getParameterTypes(); Assert.isTrue(args.length <= parameterTypes.length, "Can't specify more arguments than constructor parameters"); Object[] argsWithDefaultValues = new Object[args.length]; for (int i = 0 ; i < args.length; i++) { if (args[i] == null) { Class<?> parameterType = parameterTypes[i]; argsWithDefaultValues[i] = (parameterType.isPrimitive() ? DEFAULT_TYPE_VALUES.get(parameterType) : null); } else { argsWithDefaultValues[i] = args[i]; } } // 调用Constructor的newInstance方法，使用反射创建实例 // 到此之后bean实例创建完成 return ctor.newInstance(argsWithDefaultValues); } } catch (InstantiationException ex) { throw new BeanInstantiationException(ctor, "Is it an abstract class?", ex); } catch (IllegalAccessException ex) { throw new BeanInstantiationException(ctor, "Is the constructor accessible?", ex); } catch (IllegalArgumentException ex) { throw new BeanInstantiationException(ctor, "Illegal arguments for constructor", ex); } catch (InvocationTargetException ex) { throw new BeanInstantiationException(ctor, "Constructor threw exception", ex.getTargetException()); } }
AbstractAutowireCapableBeanFactory抽象类的中doCreateBean方法中调用的populateBean(beanName, mbd, instanceWrapper)方法¶
- 在AbstractAutowireCapableBeanFactory抽象类中的方法populateBean方法
- 该方法用于填充bean 具体发生依赖注入的地方
Java
@SuppressWarnings("deprecation") // for postProcessPropertyValues protected void populateBean(String beanName, RootBeanDefinition mbd, @Nullable BeanWrapper bw) { if (bw == null) { if (mbd.hasPropertyValues()) { throw new BeanCreationException( mbd.getResourceDescription(), beanName, "Cannot apply property values to null instance"); } else { // Skip property population phase for null instance. return; } } // Give any InstantiationAwareBeanPostProcessors the opportunity to modify the // state of the bean before properties are set. This can be used, for example, // to support styles of field injection. boolean continueWithPropertyPopulation = true; if (!mbd.isSynthetic() && hasInstantiationAwareBeanPostProcessors()) { for (BeanPostProcessor bp : getBeanPostProcessors()) { if (bp instanceof InstantiationAwareBeanPostProcessor) { InstantiationAwareBeanPostProcessor ibp = (InstantiationAwareBeanPostProcessor) bp; if (!ibp.postProcessAfterInstantiation(bw.getWrappedInstance(), beanName)) { continueWithPropertyPopulation = false; break; } } } } if (!continueWithPropertyPopulation) { return; } // 获取bean的所有属性 用于后面配置Property元素 即依赖关系 PropertyValues pvs = (mbd.hasPropertyValues() ? mbd.getPropertyValues() : null); int resolvedAutowireMode = mbd.getResolvedAutowireMode(); if (resolvedAutowireMode == AUTOWIRE_BY_NAME || resolvedAutowireMode == AUTOWIRE_BY_TYPE) { MutablePropertyValues newPvs = new MutablePropertyValues(pvs); // Add property values based on autowire by name if applicable. if (resolvedAutowireMode == AUTOWIRE_BY_NAME) { autowireByName(beanName, mbd, bw, newPvs); } // Add property values based on autowire by type if applicable. if (resolvedAutowireMode == AUTOWIRE_BY_TYPE) { autowireByType(beanName, mbd, bw, newPvs); } pvs = newPvs; } boolean hasInstAwareBpps = hasInstantiationAwareBeanPostProcessors(); boolean needsDepCheck = (mbd.getDependencyCheck() != AbstractBeanDefinition.DEPENDENCY_CHECK_NONE); PropertyDescriptor[] filteredPds = null; if (hasInstAwareBpps) { if (pvs == null) { pvs = mbd.getPropertyValues(); } for (BeanPostProcessor bp : getBeanPostProcessors()) { if (bp instanceof InstantiationAwareBeanPostProcessor) { InstantiationAwareBeanPostProcessor ibp = (InstantiationAwareBeanPostProcessor) bp; PropertyValues pvsToUse = ibp.postProcessProperties(pvs, bw.getWrappedInstance(), beanName); if (pvsToUse == null) { if (filteredPds == null) { filteredPds = filterPropertyDescriptorsForDependencyCheck(bw, mbd.allowCaching); } pvsToUse = ibp.postProcessPropertyValues(pvs, filteredPds, bw.getWrappedInstance(), beanName); if (pvsToUse == null) { return; } } pvs = pvsToUse; } } } if (needsDepCheck) { if (filteredPds == null) { filteredPds = filterPropertyDescriptorsForDependencyCheck(bw, mbd.allowCaching); } checkDependencies(beanName, mbd, filteredPds, pvs); } if (pvs != null) { // 核心逻辑 applyPropertyValues方法的具体代码在下面 applyPropertyValues(beanName, mbd, bw, pvs); } } // 上面方法中调用的applyPropertyValues方法具体代码 protected void applyPropertyValues(String beanName, BeanDefinition mbd, BeanWrapper bw, PropertyValues pvs) { if (pvs.isEmpty()) { return; } if (System.getSecurityManager() != null && bw instanceof BeanWrapperImpl) { ((BeanWrapperImpl) bw).setSecurityContext(getAccessControlContext()); } MutablePropertyValues mpvs = null; List<PropertyValue> original; if (pvs instanceof MutablePropertyValues) { mpvs = (MutablePropertyValues) pvs; if (mpvs.isConverted()) { // Shortcut: use the pre-converted values as-is. try { bw.setPropertyValues(mpvs); return; } catch (BeansException ex) { throw new BeanCreationException( mbd.getResourceDescription(), beanName, "Error setting property values", ex); } } original = mpvs.getPropertyValueList(); } else { original = Arrays.asList(pvs.getPropertyValues()); } TypeConverter converter = getCustomTypeConverter(); if (converter == null) { converter = bw; } BeanDefinitionValueResolver valueResolver = new BeanDefinitionValueResolver(this, beanName, mbd, converter); // Create a deep copy, resolving any references for values. List<PropertyValue> deepCopy = new ArrayList<>(original.size()); boolean resolveNecessary = false; for (PropertyValue pv : original) { if (pv.isConverted()) { deepCopy.add(pv); } else { String propertyName = pv.getName(); Object originalValue = pv.getValue(); if (originalValue == AutowiredPropertyMarker.INSTANCE) { Method writeMethod = bw.getPropertyDescriptor(propertyName).getWriteMethod(); if (writeMethod == null) { throw new IllegalArgumentException("Autowire marker for property without write method: " + pv); } originalValue = new DependencyDescriptor(new MethodParameter(writeMethod, 0), true); } // 获取property对应的值 resolveValueIfNecessary方法的代码在下面给出 Object resolvedValue = valueResolver.resolveValueIfNecessary(pv, originalValue); Object convertedValue = resolvedValue; boolean convertible = bw.isWritableProperty(propertyName) && !PropertyAccessorUtils.isNestedOrIndexedProperty(propertyName); if (convertible) { convertedValue = convertForProperty(resolvedValue, propertyName, bw, converter); } // Possibly store converted value in merged bean definition, // in order to avoid re-conversion for every created bean instance. if (resolvedValue == originalValue) { if (convertible) { pv.setConvertedValue(convertedValue); } deepCopy.add(pv); } else if (convertible && originalValue instanceof TypedStringValue && !((TypedStringValue) originalValue).isDynamic() && !(convertedValue instanceof Collection || ObjectUtils.isArray(convertedValue))) { pv.setConvertedValue(convertedValue); deepCopy.add(pv); } else { resolveNecessary = true; deepCopy.add(new PropertyValue(pv, convertedValue)); } } } if (mpvs != null && !resolveNecessary) { mpvs.setConverted(); } // Set our (possibly massaged) deep copy. try { // 获取到依赖的对象值后 将依赖值注入 bw.setPropertyValues(new MutablePropertyValues(deepCopy)); } catch (BeansException ex) { throw new BeanCreationException( mbd.getResourceDescription(), beanName, "Error setting property values", ex); } }
##############################################################################################################################################33¶
valueResolver.resolveValueIfNecessary(pv, originalValue);对应的方法¶
- 代码位置：org.springframework.beans.factory.support.BeanDefinitionValueResolver
Java
@Nullable public Object resolveValueIfNecessary(Object argName, @Nullable Object value) { // We must check each value to see whether it requires a runtime reference // to another bean to be resolved. if (value instanceof RuntimeBeanReference) { RuntimeBeanReference ref = (RuntimeBeanReference) value; // 核心逻辑 解决Bean依赖关系 具体代码在下方贴出 return resolveReference(argName, ref); } else if (value instanceof RuntimeBeanNameReference) { String refName = ((RuntimeBeanNameReference) value).getBeanName(); refName = String.valueOf(doEvaluate(refName)); if (!this.beanFactory.containsBean(refName)) { throw new BeanDefinitionStoreException( "Invalid bean name '" + refName + "' in bean reference for " + argName); } return refName; } else if (value instanceof BeanDefinitionHolder) { // Resolve BeanDefinitionHolder: contains BeanDefinition with name and aliases. BeanDefinitionHolder bdHolder = (BeanDefinitionHolder) value; return resolveInnerBean(argName, bdHolder.getBeanName(), bdHolder.getBeanDefinition()); } else if (value instanceof BeanDefinition) { // Resolve plain BeanDefinition, without contained name: use dummy name. BeanDefinition bd = (BeanDefinition) value; String innerBeanName = "(inner bean)" + BeanFactoryUtils.GENERATED_BEAN_NAME_SEPARATOR + ObjectUtils.getIdentityHexString(bd); return resolveInnerBean(argName, innerBeanName, bd); } else if (value instanceof DependencyDescriptor) { Set<String> autowiredBeanNames = new LinkedHashSet<>(4); Object result = this.beanFactory.resolveDependency( (DependencyDescriptor) value, this.beanName, autowiredBeanNames, this.typeConverter); for (String autowiredBeanName : autowiredBeanNames) { if (this.beanFactory.containsBean(autowiredBeanName)) { this.beanFactory.registerDependentBean(autowiredBeanName, this.beanName); } } return result; } else if (value instanceof ManagedArray) { // May need to resolve contained runtime references. ManagedArray array = (ManagedArray) value; Class<?> elementType = array.resolvedElementType; if (elementType == null) { String elementTypeName = array.getElementTypeName(); if (StringUtils.hasText(elementTypeName)) { try { elementType = ClassUtils.forName(elementTypeName, this.beanFactory.getBeanClassLoader()); array.resolvedElementType = elementType; } catch (Throwable ex) { // Improve the message by showing the context. throw new BeanCreationException( this.beanDefinition.getResourceDescription(), this.beanName, "Error resolving array type for " + argName, ex); } } else { elementType = Object.class; } } return resolveManagedArray(argName, (List<?>) value, elementType); } else if (value instanceof ManagedList) { // May need to resolve contained runtime references. return resolveManagedList(argName, (List<?>) value); } else if (value instanceof ManagedSet) { // May need to resolve contained runtime references. return resolveManagedSet(argName, (Set<?>) value); } else if (value instanceof ManagedMap) { // May need to resolve contained runtime references. return resolveManagedMap(argName, (Map<?, ?>) value); } else if (value instanceof ManagedProperties) { Properties original = (Properties) value; Properties copy = new Properties(); original.forEach((propKey, propValue) -> { if (propKey instanceof TypedStringValue) { propKey = evaluate((TypedStringValue) propKey); } if (propValue instanceof TypedStringValue) { propValue = evaluate((TypedStringValue) propValue); } if (propKey == null || propValue == null) { throw new BeanCreationException( this.beanDefinition.getResourceDescription(), this.beanName, "Error converting Properties key/value pair for " + argName + ": resolved to null"); } copy.put(propKey, propValue); }); return copy; } else if (value instanceof TypedStringValue) { // Convert value to target type here. TypedStringValue typedStringValue = (TypedStringValue) value; Object valueObject = evaluate(typedStringValue); try { Class<?> resolvedTargetType = resolveTargetType(typedStringValue); if (resolvedTargetType != null) { return this.typeConverter.convertIfNecessary(valueObject, resolvedTargetType); } else { return valueObject; } } catch (Throwable ex) { // Improve the message by showing the context. throw new BeanCreationException( this.beanDefinition.getResourceDescription(), this.beanName, "Error converting typed String value for " + argName, ex); } } else if (value instanceof NullBean) { return null; } else { return evaluate(value); } } // 上面resolveValueIfNecessary方法中调用的resolveReference方法 // 最后获取到依赖的bean @Nullable private Object resolveReference(Object argName, RuntimeBeanReference ref) { try { Object bean; Class<?> beanType = ref.getBeanType(); if (ref.isToParent()) { BeanFactory parent = this.beanFactory.getParentBeanFactory(); if (parent == null) { throw new BeanCreationException( this.beanDefinition.getResourceDescription(), this.beanName, "Cannot resolve reference to bean " + ref + " in parent factory: no parent factory available"); } if (beanType != null) { // 发生递归调用 bean = parent.getBean(beanType); } else { // 发生递归调用 根据依赖的名称从BeanFactory中递归得到依赖 最后获取到依赖的bean bean = parent.getBean(String.valueOf(doEvaluate(ref.getBeanName()))); } } else { String resolvedName; if (beanType != null) { NamedBeanHolder<?> namedBean = this.beanFactory.resolveNamedBean(beanType); bean = namedBean.getBeanInstance(); resolvedName = namedBean.getBeanName(); } else { resolvedName = String.valueOf(doEvaluate(ref.getBeanName())); bean = this.beanFactory.getBean(resolvedName); } this.beanFactory.registerDependentBean(resolvedName, this.beanName); } if (bean instanceof NullBean) { bean = null; } return bean; } catch (BeansException ex) { throw new BeanCreationException( this.beanDefinition.getResourceDescription(), this.beanName, "Cannot resolve reference to bean '" + ref.getBeanName() + "' while setting " + argName, ex); } }
AbstractPropertyAccessor的setPropertyValues(PropertyValues pvs)方法¶
- 代码位置：org.springframework.beans.AbstractPropertyAccessor
- 循环属性列表
Java
@Override public void setPropertyValues(PropertyValues pvs) throws BeansException { setPropertyValues(pvs, false, false); } // 循环属性列表 @Override public void setPropertyValues(PropertyValues pvs, boolean ignoreUnknown, boolean ignoreInvalid) throws BeansException { List<PropertyAccessException> propertyAccessExceptions = null; List<PropertyValue> propertyValues = (pvs instanceof MutablePropertyValues ? ((MutablePropertyValues) pvs).getPropertyValueList() : Arrays.asList(pvs.getPropertyValues())); // 循环属性列表 for (PropertyValue pv : propertyValues) { try { // This method may throw any BeansException, which won't be caught // here, if there is a critical failure such as no matching field. // We can attempt to deal only with less serious exceptions. // 该方法通过AbstractNestablePropertyAccessor的setPropertyValue(PropertyValue pv)方法实现 setPropertyValue(pv); } catch (NotWritablePropertyException ex) { if (!ignoreUnknown) { throw ex; } // Otherwise, just ignore it and continue... } catch (NullValueInNestedPathException ex) { if (!ignoreInvalid) { throw ex; } // Otherwise, just ignore it and continue... } catch (PropertyAccessException ex) { if (propertyAccessExceptions == null) { propertyAccessExceptions = new ArrayList<>(); } propertyAccessExceptions.add(ex); } } // If we encountered individual exceptions, throw the composite exception. if (propertyAccessExceptions != null) { PropertyAccessException[] paeArray = propertyAccessExceptions.toArray(new PropertyAccessException[0]); throw new PropertyBatchUpdateException(paeArray); } }
AbstractNestablePropertyAccessor的 setPropertyValue(PropertyValue pv)方法¶
- 代码位置：org.springframework.beans.AbstractNestablePropertyAccessor
Java
@Override public void setPropertyValue(PropertyValue pv) throws BeansException { PropertyTokenHolder tokens = (PropertyTokenHolder) pv.resolvedTokens; if (tokens == null) { String propertyName = pv.getName(); AbstractNestablePropertyAccessor nestedPa; try { nestedPa = getPropertyAccessorForPropertyPath(propertyName); } catch (NotReadablePropertyException ex) { throw new NotWritablePropertyException(getRootClass(), this.nestedPath + propertyName, "Nested property in path '" + propertyName + "' does not exist", ex); } tokens = getPropertyNameTokens(getFinalPath(nestedPa, propertyName)); if (nestedPa == this) { pv.getOriginalPropertyValue().resolvedTokens = tokens; } nestedPa.setPropertyValue(tokens, pv); } else { setPropertyValue(tokens, pv); } }
¶
- 上面setPropertyValue(PropertyValue pv)方法的重载方法setPropertyValue(PropertyTokenHolder tokens, PropertyValue pv)
- processLocalProperty(PropertyTokenHolder tokens, PropertyValue pv)方法
Java
private void processLocalProperty(PropertyTokenHolder tokens, PropertyValue pv) { PropertyHandler ph = getLocalPropertyHandler(tokens.actualName); if (ph == null || !ph.isWritable()) { if (pv.isOptional()) { if (logger.isDebugEnabled()) { logger.debug("Ignoring optional value for property '" + tokens.actualName + "' - property not found on bean class [" + getRootClass().getName() + "]"); } return; } else { throw createNotWritablePropertyException(tokens.canonicalName); } } Object oldValue = null; try { Object originalValue = pv.getValue();// Object valueToApply = originalValue;// if (!Boolean.FALSE.equals(pv.conversionNecessary)) { if (pv.isConverted()) { valueToApply = pv.getConvertedValue(); } else { if (isExtractOldValueForEditor() && ph.isReadable()) { try { oldValue = ph.getValue(); } catch (Exception ex) { if (ex instanceof PrivilegedActionException) { ex = ((PrivilegedActionException) ex).getException(); } if (logger.isDebugEnabled()) { logger.debug("Could not read previous value of property '" + this.nestedPath + tokens.canonicalName + "'", ex); } } } valueToApply = convertForProperty( tokens.canonicalName, oldValue, originalValue, ph.toTypeDescriptor()); } pv.getOriginalPropertyValue().conversionNecessary = (valueToApply != originalValue); } ph.setValue(valueToApply);// 具体代码在下方列出 } catch (TypeMismatchException ex) { throw ex; } catch (InvocationTargetException ex) { PropertyChangeEvent propertyChangeEvent = new PropertyChangeEvent( getRootInstance(), this.nestedPath + tokens.canonicalName, oldValue, pv.getValue()); if (ex.getTargetException() instanceof ClassCastException) { throw new TypeMismatchException(propertyChangeEvent, ph.getPropertyType(), ex.getTargetException()); } else { Throwable cause = ex.getTargetException(); if (cause instanceof UndeclaredThrowableException) { // May happen e.g. with Groovy-generated methods cause = cause.getCause(); } throw new MethodInvocationException(propertyChangeEvent, cause); } } catch (Exception ex) { PropertyChangeEvent pce = new PropertyChangeEvent( getRootInstance(), this.nestedPath + tokens.canonicalName, oldValue, pv.getValue()); throw new MethodInvocationException(pce, ex); } }
¶
- 上述ph.setValue方法在org.springframework.beans.AbstractNestablePropertyAccessor抽象类中定义
- public abstract void setValue(@Nullable Object value) throws Exception;
- 一个具体实现在org.springframework.beans.BeanWrapperImp的内部类BeanPropertyHandler中，完整代码如下：
Java
private final PropertyDescriptor pd; //BeanPropertyHandler中的字段 @Override public void setValue(final @Nullable Object value) throws Exception { final Method writeMethod = (this.pd instanceof GenericTypeAwarePropertyDescriptor ? ((GenericTypeAwarePropertyDescriptor) this.pd).getWriteMethodForActualAccess() : this.pd.getWriteMethod());// 找到属性的set方法 if (System.getSecurityManager() != null) { AccessController.doPrivileged((PrivilegedAction<Object>) () -> { ReflectionUtils.makeAccessible(writeMethod); return null; }); try { AccessController.doPrivileged((PrivilegedExceptionAction<Object>) () -> writeMethod.invoke(getWrappedInstance(), value), acc); // 调用Method的invoke方法，完成属性注入 } catch (PrivilegedActionException ex) { throw ex.getException(); } } else { ReflectionUtils.makeAccessible(writeMethod); writeMethod.invoke(getWrappedInstance(), value);//调用Method的invoke方法，完成属性注入 } } - 至此Ioc容器的启动过程基本结束
15. finishRefresh();方法¶
- org.springframework.context.support.AbstractApplicationContext中的finishRefresh()方法
Java
protected void finishRefresh() {
// Clear context-level resource caches (such as ASM metadata from scanning).
clearResourceCaches();
// Initialize lifecycle processor for this context.
initLifecycleProcessor();
// Propagate refresh to lifecycle processor first.
getLifecycleProcessor().onRefresh();
// Publish the final event.
publishEvent(new ContextRefreshedEvent(this));
// Participate in LiveBeansView MBean, if active.
LiveBeansView.registerApplicationContext(this);
}
16refresh()过程抛出异常时¶
- 之中有两个处理方法destroyBeans()和cancelRefresh(ex)
16.1 destroyBeans();方法¶
- org.springframework.context.support.AbstractApplicationContext中的destroyBeans()方法
16.2 cancelRefresh(ex);方法¶
- org.springframework.context.support.AbstractApplicationContext中的cancelRefresh(ex)方法
16.3抛出异常BeansException¶
17 resetCommonCaches();方法¶
- org.springframework.context.support.AbstractApplicationContext中的resetCommonCaches()方法
- try-catch-finally代码块中finally包裹的方法
- 执行到此Ioc容器启动完成，可以正式投入使用
总结¶
- Ioc的底层原理实现：Spring Ioc启动分为两步：
- 1.创建BeanFactory
- 2.实例化Bean
- Spring的Bean在内存中的状态就是BeanDefination
- 在Bean的创建和依赖注入的过程中，需要根据BeanDefination的信息来递归的完成依赖注入，从代码可以看到，这些递归都是以getBean()为入口的，一个递归是在上下文体系中查找需要的bean和bean的依赖关系；另一个递归是在依赖注入时，通过递归调用容器的getBean方法得到当前依赖的Bean，同时也触发对依赖bean的创建和注入。在对bean的属性进行依赖注入时，解析过程也是一个递归过程，这样根据依赖关系，一层一层的完成Bean的创建和注入，直到当前bean相关的整个依赖链的注入完成。由于整个IoC容器启动过程较为复杂，使用下面的一张图来描述让读者更清楚厘清IoC容器的启动过程。
模板¶
- 代码位置:org.springframework.context.support.AbstractApplicationContext.java
-
代码位置:org.springframework.context.support.AbstractApplicationContext.java
-
代码位置:.java
-
代码位置:.java
参考资料¶
- Spring源码深度解析（第二版） 郝佳
- Spring5企业级开发实战 周冠亚 黄文毅 配套源码
- Gitee同步版本：https://gitee.com/ACANX/spring5projectdemo
最后更新:
2025-05-15
